Development of 36kV/10kW charging power supply used in CO2 laser
-
摘要: 为了改善现有CO2激光器工频LC谐振充电时充电电压随激光器工作频率升高而降低、影响激光输出的稳定性和光束质量,不利于装置的小型化和轻量化的问题。采用全桥逆变结构和串联谐振软开关电路,研究了36kV/10kW高频高压充电电源。该电源系统采用三相380V交流电作为供电系统,大功率智能功率模块作为全桥逆变电路。逆变交流信号经串联谐振电路及高频脉冲变压器得到高压脉冲信号,高压脉冲经整流给负载电容充电,电源应用电压电流双闭环控制系统,输出电压、电流经采样及放大后,反馈到电源控制芯片SG3525,芯片SG3525通过判断反馈信号的大小,控制输出脉冲宽度调制驱动信号的占空比。激光器放电频率为25Hz时,电源输出电压为37kV,峰值输出功率为13.05kW,充电效率为0.826。结果表明,该高频高压充电电源适合用作CO2激光器的高压充电电源。Abstract: The output voltage of a traditional high voltage charging power supply of CO2 laser in LC resonant charging configuration drops with the increase of operating frequency, which affect the stability of laser output and the beam quality. Meanwhile, traditional high voltage charging power supply has huge size and weight which is disadvantageous to small size and weight of the device. In order to resolve the problems, a 36kV/10kW high frequency and high voltage charging power supply was studied by using a full bridge inverter circuit and a series resonant soft switch circuit. Three phase 380V alternating current (AC) was used as the energy system, high power intelligent power module(IPM) was used as full bridge inverter circuit. High voltage pulse signal was obtained by the inverter AC signal through series resonant circuit and high frequency pulse transformer. High voltage pulse charged power supply for load capacitor through rectifier. Voltage and current double closed-loop control system was used in the charging power. After sampling and amplification, the output voltage and current were fed back to the power supply control chip SG3525. SG3525 controlled the duty cycle of pulse width modulation driving signal by feedback signal. Experimental results show that the output voltage of the charging power supply is 37kV, output peak power is 13.05kW, and charging efficiency is 0.826 when laser discharge frequency is 25Hz. The high frequency and high voltage charging power supply is suit for high voltage charging power of CO2 laser.
-
-
[1] BEKEY I. Project Drion:orbit debris removal using ground basedsensors and laser[C]//Proceedings of the Second European Conference on Space Debris.Darmstadt,Germany:European Space Agency,1996:699-701.
[2] HASSON V. Review of design concepts and diagnostics for 100kW class repetitive pulsed CO2 laser[J]. SPIE, 2003, 5120:717-730.
[3] GONSALVES J N, DULEY W W. Cutting thin metal sheets with the CW CO2 laser[J]. Journal of Applied Physics, 1972, 43(11):4684-4687.
[4] TSUNERNI A, HAGIWARA K, SAITO N, et al. Complete removal of paint from metal surgace by ablation with a TEA CO2 laser[J]. Applying Physics, 1996, 63(2):435-439.
[5] ROBERT B. A compact switched-capacitor regulated chargepump power supply[J]. IEEE Journal of Solid-State Circuits, 2006,41(8):1944-1953.
[6] MENG F J. Application of digital signal processor on high power TEA CO2 laser control system[D]. Changchun:Jilin University, 2008:12-15(in Chinese).
[7] MENG F J, GUO L H, YANG G L, et al. Suppression of electromagnetic interference in high power TEA CO2 laser system[J]. High Power Laser and Particle Beams, 2008, 20(2):177-181(in Chinese).
[8] ZHANG X L, GUO L H, MENG F J, et al. Application of series resonant charging technology to trigger system for rotated spark switch[J].Optics and Precision Engineering, 2015, 23(5):1416-1423(in Chinese).
[9] WANG M, TIAN Y, LI T M, et al. Study of bidirectional DC-DC converters applied to energy storage syetem[J].Transations of China Electrotechnical Society, 2013, 28(8):65-70(in Chinese).
[10] LIN Z Q. Research of high power TEA CO2 laser full-bridge power supply with series resonant mode[D]. Beijing:Beijing Jiaotong University, 2012:25-40(in Chinese).
[11] KOPELOVICH E A, VANYAEV V V, KHVATOV S V. Features of electromagnetic processesin high voltage power supplies with a series resonant inverter[J]. Russian Electrical Engineering, 2011, 82(10):523-528.
[12] DO L H. Soft-switching high step-up DC-DC converter with single magnetic component[J]. International Journal of Circuit Theory and Application, 2014, 42(6):620-631.
[13] ZHANG J H, LAI J S, YU W S, et al. High-power density design of a soft-switching high-power bidirectional dc-dc converter[J]. IEEE Transactions on Power Electronics, 2007, 22(4):1145-1152.
[14] KANG W, ZHANG L X, LIU C Y. Output filter design method in current-source PWM converters[J].Transations of China Electrotechnical Society, 2012, 27(6):83-89(in Chinese).
[15] YANG D S, RUAN X B, LI Y, et al. A new multiple-input full bridge converter[J]. Transations of China Electrotechnical Society, 2011, 26(8):24-32(in Chinese).
[16] FILCHEV T, CARASTRO F, WHEELER P, et al. High voltage high frequency power transformer for pulsed power application[C]//14th International Power Electronics and Motion Control Conference.New York,USA:IEEE,2010:165-170.
[17] ZHANG Y, LIU J L, CHENG X B, et al. Output characteristics of a kind of high-voltage pulse transformer with closed magnetic core[J].IEEE Transactions on Plasma Science, 2010, 38(4):1019-1027.
[18] DALESSANDRO L, da SILVERIA CAVALCANTE F, KOLAR J W, et al. Self-capacitance of high-voltage transformers[J]. IEEE Transactions on Power Electronics, 2007, 22(5):2081-2092.
[19] TRANSFORMER MANUFACTURING PIPELINE COMMITTEE. Electronic transformer manual[M]. Shenyang:Liaoning Science and Technology Publishing House, 1999:392-394(in Chinese).
-
