Study of the optimum operating mode in lithium niobate acousto-electro-optic modulator
-
摘要: 为进一步提高铌酸锂声电光调制器的性能,在确定器件的电光工作模式后,利用相切条件办法对相应的声光工作模式进行了系统的研究。通过以离轴角为自变量分别对x-O-z平面和y-O-z平面内不同超声波情况下的声光优值进行定量计算,确定了铌酸锂声电光器件的最佳工作模式,并给出了该工作模式下中心频率在50MHz~300MHz之间铌酸锂声电光器件的设计参数。计算结果表明,利用最优化工作模式可以获得较大的声光优值,从而有效提高器件的衍射效率。Abstract: In order to improve the performance of lithium niobate acousto-electro-optic(AEO) modulator,the acousto-optic operating modes were systematically studied according to tangent condition after the determination of electro-optic operating mode.Acousto-optic merit for sheared ultrasonic wave in x-O-z plane and y-O-z plane were calculated respectively and the optimum operating mode for lithium niobate AEO modulator was determined.Furthermore,the design parameters for central frequency in range of 50MHz～300MHz were also given.By this optimum operating mode,the AEO device can gain a higher acousto-optic merit and achieve a higher diffractive efficiency.
-
Keywords:
- optical devices /
- acousto-optic merit /
- tangent condition /
- lithium niobate
-
-
[1] HE Sh Zh,YAO X,JIANG Ch Zh.Study on demodulation system of laser Doppler[J].Laser Technology,2004,28(2):190～192(in Chinese).
[2] YAO J H,YAN B X,CHEN Y H.Periodical poled second harmonic green light generation in near-stoichiometric MgO-doped LiNbO3 crystal[J].Laser Technology,2004,28(2):141～143(in Chinese).
[3] WEIS R S.Lithium niobate:summary of physical properties and crystal structure[J].Appl Phys,1985,A37(3):191～201.
[4] PSALTIS D.Acousto-electro-optic light modulation[J].A P L,1985,46(3):215～2193.
[5] LEE H.Acousto-electro-optic deflector[J].A P L,1986,49(1):24～28.
[6] YU K X,ZHAO Q D,HE Sh Y.Acousto-electro-optic effect and acousto-electro-optic device[J].Acta Optica Sinica,1997,17(2):253～256(in Chinese).
[7] YU K X,SHI X J,ZHAO B S.Study of acousto-optic diffraction geometry in TeO2 crystal by tangent condition[J].Journal of Beijing University of Technology,2002,28(2):211～215(in Chinese).
[8] YU K X,LIU Ch Sh,ZHANG D H.Anisotropic acouyto-optic interaction geometries in lithium niobate crystals[J].Journal of Data Acquisition and Processing,1996,11(2):123～126(in Chinese).
[9] YU K X,ZHAO B S,HE Sh Y.Determination of optimum operating mode for three-dimensional anisotropic acousto-electro-optic interaction[J].Piezoelectrics Acoustooptics,2003,25(1):11～14(in Chinese).
[10] XU J P.Principle,design and application of acousto-optic device[M].Beijing:Science Press,1982.65～66(in Chinese).
-
