Study on laser-induced chemical liquid deposition Fe film
-
摘要: 为了沉积出表面平整、尺寸精确、沉积区域具有可选择性的Fe膜,采用YAG固体激光器,以Fe(CO)5为液相前驱体,利用一定厚度的石英片减少副产物,在激光功率密度为1.0106W/cm2、激光频率为2.5kHz、激光扫描速率为300mm/s、激光重复扫描次数为200次的条件下,沉积出表面平整性较好、并且具有一定厚度的Fe沉积层。通过测试分析发现,沉积层表面质量受激光功率密度影响较大;激光功率密度是影响到沉积层能否沉积以及沉积厚度的重要参量。结果表明,通过激光诱导,以Fe(CO)5为前驱体,可以实现铜表面的Fe膜的沉积。Abstract: To deposit Fe film with smooth surface, accurate dimension, deposition area of optional nature, a YAG solid-state laser was used, Fe(CO)5 was used as liquid precursor and a certain thickness quartz plate was adopted to reduce byproducts. At the condition of laser power density of 1.0106W/cm2, laser frequency of 2.5kHz, laser scanning speed of 300mm/s and scan repetition of 200 times, a Fe layer in a certain thickness was deposited with better surface flatness. Experimental results show that laser power density influences surface quality of deposition layer stronger. Laser power intensity is one of the most important parameters determining whether the layer is deposited or not and the thickness of the layer. The results show that by laser-induced and using Fe(CO)5 as precursor, Fe film deposition can be achieved on copper surfaces.
-
-
[1] ABUDUREXITI A,ZAKIR A,TUNIYAZI P.Effect of laser power density on self-generated magnetic field and electron thermal conduction[J].Laser Technology,2013,37(1):134-138(in Chinese).
[2] LI C J,MA B X,JIN Z H.A review of chemical vapor deposition/infiltration technology[J].Journal of Solid Rocket Technology,1999,22(1):54-58(in Chinese).
[3] LIU L B,ZHAO Y,LIU M H,et al.Three-dimensional microfabrication by laser-induced chemical deposition[J].Applied Laser,2002,22(2):160-164(in Chinese).
[4] LIU L B,ZHAO Y,LIU M.Laser-induced selective deposition of copper on common glass from solution[J].Laser Journal,2002,23(3):51-52(in Chinese).
[5] LIU J G,CHEN C H, ZHENG J S.Study of CO2 laser induced liquid-phase local deposition technique[J].Chinese Journal of Lasers,2003,30(9):859-863(in Chinese).
[6] LIU J G,CHEN C H,ZHENG J X.Mechanism of CO2 laser-induced liquid deposition of silver[J].Laser Journal,2004,25(4):82-84(in Chinese).
[7] CHEN C H,LIU J G.The mechanism of CO2 laser-induced metal deposition from aqueous solution[J].Laser Technology,2005,29(8):383-385(in Chinese).
[8] AO Y H,HU S L,LONG, et al. Study on pulsed laser deposition technology[J].Laser Technology,2003,27(5):453-459(in Ch-inese).
[9] LIU J G,CHEN C H,ZHENG J X.Experimental study of CO2 laser induced locally chemical depositions of copper[J].Laser Technology,2003,27(1):16-18(in Chinese).
[10] WANG Z M,JI M,ZENG X Y.Study on deposition mode and rate in pulsed laser deposition of Al film[J].Laser Technology,2006,30(3):265-310(in Chinese).
[11] GONG Y Sh,TU R,GOTO T.High-speed deposition of oriented TiNx films by laser metal-organic chemical vapor deposition[J].Journal of Inorganic Materials,2010,25(4):391-395(in Chinese).
[12] YAMPAREDD E,KOVACEVIC R.Synthesis and characterization of laser-based direct metal deposited nano-particles reinforced surface coatings for industrial slurry erosion applications[J].Surface Coatings Technology,2008,202(10):1951-1965.
[13] QIU X W.Microstructure and properties of laser transformation hardening layer on 1Cr18Ni9Ti[J].Laser Technology,2011,35(3):425-432(in Chinese).
[14] SUN K,ZHAO Y,ZHANG C B,et al.Pulsed Nd:YAG laser induced chemical deposition of Ag[J].Journal of Northeastern University (Natural Science Edition),2002,23(4):391-393(in Chinese).
[15] WANG C C,MA J,BI A G,et al.Microstructures and properties of molybdenum coating prepared by chemical vapor deposition[J].Transactions of Materials and Heat Treatment,2005,26(3):51-54(in Chinese).
-
