Calculation of diffraction efficiency of volume Bragg gratings with rigorous coupled-wave method
-
摘要: 为了获得更精确的光栅衍射效率,采用严格耦合波理论建立体布喇格光栅衍射机理模型,分析了运用严格耦合波理论实现体光栅的衍射效率计算,并利用正交Legendre多项式展开法求解耦合波方程,取得了体布喇格光栅衍射效率稳定的数值解,得到的仿真结果符合理论计算。结果表明,相对于矩阵法,该算法具有更好的收敛速率,且比Ko-gelnik耦合波理论解法更精确。
-
关键词:
- 衍射与光栅 /
- 体布喇格光栅 /
- 严格耦合波理论 /
- 衍射效率 /
- Legendre多项式
Abstract: In order to obtain the accurate diffraction efficiency of gratings,the diffraction mechanism of volume Bragg gratings was established and the diffraction efficiency was calculated with the rigorous coupled-wave method.The first-order coupled Maxwell's equations was solved in terms of Legendre polynomials,and the diffraction efficiency of volume Bragg gratings was obtained.The simulation results were consistent with theoretical calculation results.This method converges faster than the matrix method,and is more precise than the Kogelnik coupling wave theory. -
-
[1] EFIMOV 0 M,GLEBOV L B,SMIRNOV V I.Diffractive optical elements in photosensitive inorganic glasses[J].Proceedings of SPIE,2001,4452:392.
[1] EFIMOV O M,GLEBOV L B,SMIRNOV V I.High efficiency volume diffractive elements in photo-thermo-refractive glass:US,6673497[P].2004-01-06.
[2] GLEBOV L B,GLEBOVA L.Swelling of photo-thermo-refractive glass resulted from thermal development[J].Glaass Science and Technology,2002,75 (c2):294-297.
[3] GLEBOV L B.PTR glass melting facility for fabrication of diff ractive optical elements[R].Virginia,USA:America Diabetes Association,2004:650126.
[4] ZHOU P,HOU J,CHEN Z L,et al.Comparative study for coherent beam combining and spectral beam combining of fiber lasers[J].Laser Technology,2008,32(4):413416(in Chinese).
[5] KOGELNIK H.Could wave theory for thick hologram gratings[J].Bell Systems Technical Journal,1969,48(9):2909-2945.
[6] DEFOSSE Y,RENOTTE Y L M,LION Y F.Calculation of diffraction efficiencies for spherical and cylindrical holographic lenses[J].Proceedings of SPIE,1991,1507:277-287.
[7] THOLL H D.Two-wave coupled-wave theory of the polarizing properties of volume phase gratings[J].Proceodings of SPIE,1991,1555:101-111.
[8] BLESA A,ARIAS I,ATENCIA J,et al.Holographic volume dual-element as an optical variable beansplitter[J].Journal of Modern Optics,1999,46 (1):155-165.
[9] NEIPP E,PASCUAL I,BELENDEZ A.Experimental evidence of mixed gratings with a phase diference between the phase and amplitude grating in volume,holograms[J].Optics Express,2002,10(23):1374-1383.
[10] GALLEGO S,ORTUNO M,NEIPP C,et al.Overmodulation effects in volume holograms recorded on photopolymers[J].Optics Communications,2003,215 (4/6):263-269.
[11] MOHARAM M G,GAYLORD T K.Rigorous coupledwave analysis of planar-grating diffraction[J].Journal of the Optical Society of America,1981,71 (7):811-818.
[12] KHAVASI A,MEHRANY K.Three-dimensional diffraction analysis of gratings based on Legendre expansion of electromagnetic fields[J].Journal d the Optical Society of America,2007,24(10):2627-2685.
