基于量子点光放大器波长转换的啁啾特性研究

陈廷廷; 王海龙; 刘松; 龚谦

doi:10.7510/jgjs.issn.1001-3806.2016.02.030

基于量子点光放大器波长转换的啁啾特性研究

1.
曲阜师范大学物理工程学院, 曲阜 273165;
2.
中国科学院上海微系统与信息技术研究所信息功能材料国家重点实验室, 上海 200050

作者简介: 陈廷廷(1989-),女,硕士研究生,主要研究方向为光通信与光信息技术。.

通讯作者: 王海龙, hlwang@mail.qfnu.edu.cn ;

基金项目:
国家自然科学基金资助项目(60976015;61176065);山东省自然科学基金资助项目(ZR2010FM023);信息功能材料国家重点实验开放课题资助项目(SKL201307)
中图分类号: TN929.11

Theoretical study on chirp of wavelength conversion based on QD-SOA

1.
College of Physics and Engineering, Qufu Normal University, Qufu 273165, China;
2.
State Key Laboratory of Functional Materials for Informatics, Shanghai Institute of Microsystem and Information Technology, Chinese Academy of Sciences, Shanghai 200050, China

Corresponding author: WANG Hailong, hlwang@mail.qfnu.edu.cn ;

CLC number: TN929.11

摘要: 信号光的啁啾特性在很大程度上会影响量子点半导体光放大器(QD-SOA)的性能,引起传输信号的走离效应,使误比特率增高。为了改善这一特性,对QD-SOA全光波长转换器的啁啾特性进行了系统分析,基于QD-SOA的交叉增益调制效应的全光波长转换原理,采用牛顿法和4阶龙格-库塔法求解速率方程和光场传输方程,计算了注入电流、抽运光脉宽和抽运光消光比变化时QD-SOA全光波长转换器输出变换光的啁啾值。结果表明,增大抽运光脉宽、减小注入电流和抽运光消光比均可减小变换光的啁啾值,通过优化这些参量可以减小啁啾的影响,但在设计QD-SOA全光波长转换器时,要考虑抽运光消光比和变换光啁啾之间的均衡。
- 光通信 /
- 量子点光放大器 /
- 啁啾 /
- 交叉增益调制
Abstract: Chirp characteristics of signal light can largely affect the performance of quantum-dot semiconductor optical amplifiers (QD-SOA), cause the walk-off effect of transmitted signal and increase the bit error rate. To improve this situation, chirp characteristics of QD-SOA all-optical wavelength converters were analyzed. Based on all-optical wavelength conversion principle of QD-SOA's cross-gain modulation (XGM), using Newton's method and 4-order Runge-Kutta method, rate equations and light field transmission equation were solved, chirp values of converted light of a QD-SOA all-optical wavelength converter were calculated with the change of injection current, pumping light pulse width and extinction ratio of pumping light. The results show that increasing pulse width of pumping light, reducing injection current and extinction ratio of pumping light can reduce the chirp value of converted light. The impact of chirp can be reduced by optimizing these parameters. But during the design of QD-SOA all-optical wavelength converters, the balance between extinction ratio of pump light and chirp of conversion light should be considered.
- optical communication /
- quantum-dot semiconductor optical amplifier /
- chirp /
- cross-gain modulation

[1]	VAZQUEZ J M, ZHANG J Z, GALBRAITH I. Quantum dot versus quantum well semiconductor optical amplifiers for subpicosecond pulse amplification[J]. Optical and Quantum Electronics, 2004, 36(6):539-549.
[2]	QASAOMEH O. Characteristics of cross gain(XG) wavelength conversion in quantum dot semiconductor optical amplifiers[J]. IEEE Photonics Technology Letters, 2004, 16(2):542-544.
[3]	SHAO Y T, LUO B, PAN W. Novel all-optical logic AND gate based on semiconductor optical amplifier[J]. Laser Technology, 2009, 33(3):314-318(in Chinese).
[4]	LI Y J. Research of analog signal's cross phase modulation in SOA[J]. Laser Technology, 2010, 34(4):573-576(in Chinese).
[5]	CONTESTABILE G, MARUTA A, SEKIGUCHI S, et al. All-optical wavelength multicasting in a QD-SOA[J]. IEEE Journal of Quantum Electronics, 2011, 47(4):541-547.
[6]	LI P L, HUANG D X, ZHANG X L, et al. Wavelength converter based on cross-gain modulation in multi-electrode single-port-coupled semiconductor optical amplifier[J]. Acta Physica Sinica, 2006, 55(6):2746-2750(in Chinese).
[7]	JUNGHO K, LAEMMLIN M, MEUER C, et al. Theoretical and experimental study of high-speed small-signal cross-gain modulation of quantum-dot semiconductor optical amplifiers[J]. IEEE Journal of Quantum Electronics, 2009, 45(3):240-248.
[8]	CONTESTABILE G, MARUTA A, SEKIGUCHI S, et al. Cross-gain modulation in quantum-dot SOA at 1550nm[J]. IEEE Journal of Quantum Electronics, 2010, 46(12):1696-1703.
[9]	WATANABE T, SAKAIDA N, YASAKA H, et al. Transmission performance of chirp controlled signal by using semiconductor optical amplifier[J]. Journal of Lightwave Technology, 2000, 18(8):1069-1077.
[10]	DONG J J, ZHANG X L, HUANG D X. Chirp characteristics in wavelength converter based on single-port-coupled SOA[J]. Acta Photonica Sinica, 2005,34(2):255-258(in Chinese).
[11]	YE Y B, ZHENG X P, ZHANG H Y, et al. Chirp performance of converted signal in wavelength conversion based on cross-gain modulation in SOA[J]. Acta Optica Sinica, 2002, 22(4):436-440(in Chinese).
[12]	FENG J H, JI Y F, CHEN Sh Q, et al. Converted signal chirp of all-optical-wavelength-converters based on cross-gian modulation in SOA caused by phase modulated[J]. Chinese Journal of Lasers, 2001, 28(6):545-548(in Chinese).
[13]	EZRA Y B, LEMBRIKOV B I, HARIDIM M. Specific features of XGM in QD-SOA[J]. IEEE Journal of Quantum Electronics, 2007, 43(8):730-737.
[14]	YU J X. All-optical logic gate using cross-gain modulation of quantum-dot semiconductor optical amplifier[D]. Chengdu:Southwest Jiaotong University, 2011:16-19(in Chinese).
[15]	EZRA Y B, HARIDIM M, LEMBRIKOV B I. Theoretical analysis of gain-recovery time and chirp in QD-SOA[J]. IEEE Photonics Technology Letters, 2005, 17(9):1803-1805.
[16]	LI X X, LI G F. Comments on theoretical analysis of gain recovery time and chirp in QD-SOA[J]. IEEE Photonics Technology Letters, 2006, 18(22):2434-2435.
[17]	CONNELLY M J. Wideband semiconductor optical amplifier steady-state numerical model[J]. IEEE Journal of Quantum Electronics, 2001, 37(3):439-447.
[18]	NEWELL T C, BOSSERT D J, STINTZ A, et al. Gain and linewidth enhancement factor in InAs quantum-dot laser diodes[J]. IEEE Photonic Technology Letters, 1999, 11(12):1527-1529.
[19]	SCHNEIDER S, BORRI P, LANGBEIN W, et al. Linewidth enhancement factor in InGaAs quantum-dot amplifiers[J]. IEEE Journal of Quantum Electronics, 2004, 40(10):1423-1429.
