Laser heterodyne interference signal processing system based on AD8302
-
摘要: 为了改善传统硬件相位测量中存在电路复杂、测量精度低、工作频带宽窄等诸多缺陷,利用AD8302的良好高频测相能力,设计了一种新的激光外差干涉信号处理系统,分析了其工作原理,并取得了静态、动态实验数据。结果表明,系统测量误差小于0.5,使外差干涉理论测量分辨率提高到0.088nm,更有利于微振动信号的测量。Abstract: In order to overcome defects of the traditional phase measurement hardware, such as circuit complexity, low measurement precision and narrow band width, a novel signal processing system of a laser heterodyne interferometer was designed based on AD8302 with good performance. The work theory of the system was analyzed in detail. Static and dynamic experimental data were obtained. The results show that measurement error of the system is less than 0.5 and the measurement resolution of heterodyne interference can reach 0.088nm in theory which is more conductive to measure the microvibration signal.
-
-
[1] JOO K N, ELLIS J D, BUICE E S, et al. High resolution heterodyne interferometer without detectable periodic nonlinearity[J]. Optics Express,2010,18(2):1159-1165.
[2] KIM M S, KIM S W. Two-way frequency-conversion phase measurement for high-speed and high-resolution heterodyne interferometer [J]. Measurement Science and Technology, 2004, 15(11):2341-2348.
[3] ZHAO S W, YAN L P, YANG T. Signal processing method of the laser heterodyne interferometer based on DSP [J]. Journal of Zhejiang Institute of Science and Technology,2011,28(2):217-220(in Chinese).
[4] LU Sh, LOU L F, WANG Ch. Research of signal hardware demodulating technique in fiber interferometer vibration measurement[J]. Chinese Journal of Sensors and Actuators,2013,26(7):932-935(in Chinese).
[5] WEI J Q, ZHANG T, HE Z N, et al. Signal processing system of dual-frequency laser interferometer with two longitudinal modes based on AD8302[J]. China Measurement Test, 2009, 35(3):52-55(in Chinese).
[6] LI L. Research on radio locating system of test bomb falling point in missile range[D].Taiyuan:North University of China, 2009:1-65(in Chinese).
[7] CAO L J. A new measuring system of phase and amplitude based on AD8302 [J]. Electronic Engineer,2007,33(3):6-8(in Chinese).
[8] MONCHALIN J P. Heterodyne interferometer laser probe to measure continuous ultrasonic displacement [J].Review of Scientific Instruments, 1985, 56(4):543-546.
[9] SHA Zh Y, LIU A F, WANG K. Design of single-chip broad band phase biasmeasure system based on AD8302[J]. International Electronic Elements,2006(1):57-60(in Chinese).
[10] JIA X G. Design and analysis of transceiver system of SAW sensor in TPMS[D]. Harbin:Harbin Institute of Technology, 2010:1-67(in Chinese).
[11] ZHANG J. Research of eddy current testing method for drill pipe thread[D]. Shenyang:Shenyang University of Technology, 2009:1-72(in Chinese)
[13] WU D, ZHU R H, CHEN L. Heterodyne vibration measurement and signal processing for environmental micro-disturbances on phase-shifting interferometer [J]. Opto-Electronic Engineering, 2004, 31(9):53-56(in Chinese).
[14] YEE Y F, CHAKRABARTY C K. Phase detection using AD8302 evaluation board in the super heterodyne microwave interferometer for line average plasma electron density measurements[J].Measurement, 2007,40(9):849-853.
