耦合式光电振荡器的理论与实验研究

徐伟; 金韬; 池灏

doi:10.7510/jgjs.issn.1001-3806.2014.05.001

耦合式光电振荡器的理论与实验研究

1.
浙江大学信息与电子工程学系, 杭州 310027

作者简介: 徐伟（1988-），男，硕士研究生，现主要从事光通信和微波光子学的研究。.

通讯作者: 金韬, jint@zju.edu.cn ;

基金项目:
国家自然科学基金资助项目（61275027）
中图分类号: TN751.1

Theoretical and experimental research of coupled optoelectronic oscillators

1.
Department of Information Science and Electronic Engineering, Zhejiang University, Hangzhou 310027, China

Corresponding author: JIN Tao, jint@zju.edu.cn ;

CLC number: TN751.1

摘要: 为了研究耦合式光电振荡器，阐述了耦合式光电振荡器的模式选择理论，给出了维持最佳锁模状态的相位匹配条件，分析了影响射频信号相位噪声的因素，进行了基于保偏机制的耦合式光电振荡器的实验研究。采用分别调节光环形腔和光电微波振荡环路中的保偏可变光纤延迟线可改变腔长的方法，获得了腔长与振荡频率的关系。同时，采用鉴频法测量了不同条件下5GHz射频信号的相位噪声，研究了影响射频信号相位噪声的因素。结果表明，耦合式光电振荡器的振荡模式取决于光环形腔的腔长，射频信号相位噪声受到光信号偏振态、相位匹配、环路长度等因素的影响。实验中获得了偏移频率10kHz处相位噪声达到-136dBc/Hz的5GHz射频信号，是目前国内已知的相位噪声最低的耦合式光电振荡器。
- 光电子学 /
- 耦合式光电振荡器 /
- 振荡模式 /
- 相位匹配 /
- 保偏 /
- 相位噪声
Abstract: In order to study coupled optoelectronic oscillators (COEO) further, the mode selection theory of COEO was expounded. The phase matching condition to maintain optimum mode-locked state was given. The affecting factors of phase noise of radio frequency signal were analyzed. The experiment of COEO based on polarization-maintaining mechanism was conducted. By adjusting the polarization-maintaining variable optical fiber delay lines in the optical ring cavity and the optoelectric microwave oscillation loop to change the cavity length, the relationship between cavity length and oscillation frequency was obtained. Meanwhile, by using the frequency discrimination method, phase noise performances of 5GHz radio frequency(RF) signals under different operating conditions were measured and the effective factors were studied. The experimental results demonstrate that oscillation mode depends on the cavity length of optical ring cavity. Optical signal polarization, phase matching and loop length have influence on the phase noise of the RF signals. The coupled optoelectronic oscillator of 5GHz RF signal and phase noises of -136dBc/Hz at 10kHz offset frequency is obtained, whose phase noise is the lowest in our country as far as we know.
- optoelectronics /
- coupled optoelectronic oscillator /
- oscillation mode /
- phase match /
- polarization-maintaining /
- phase noise

[1]	YAO X S, MALIKI L. Converting light into spectrally pure microwave oscillation [J]. Optics Letters, 1996, 12(7): 483-485.
[2]	YAO X S, MALIKI L. Optoelectronic microwave oscillator [J].Journal of the Optical Society of America, 1996,B13(8):1725-1735.
[3]	NAKAZAWA M, YOSHIDA E, KIMURA Y. Ultrastable harmonically and regeneratively modelocked polarization-maintain erbium fiber laser [J]. Electronics Letters, 1994, 30(19):1603-1605.
[4]	NAKAZAWA M, YOSHIDA E, TAMURA K. 10GHz, 2ps regeneratively and harmonically FM mode-locked erbium fiber ring laser [J]. Electronics Letters, 1996, 32(14):1285-1287.
[5]	NAKAZAWA M, YOSHIDA E, TAMURA K. Ideal phase-locked-loop (PLL)operation of a 10GHz erbium-doped fiber laser using regenerative mode-locking as an optical voltage controlled oscillator [J]. Electronics Letters, 1997, 33(15):1318-1320.
[6]	WANG Z Y, JIA D F, GE C F. Generation of supercontinuum by using rengeratively mode-locked fiber laser [J]. Journal of Optoelectronics稬aser 2006, 17(1):9-13(in Chinese).
[7]	YAO X S, DAVIS L, MALIKI L. Coupled optoelectronic oscillators for generating both RF signal and optical pulses [J]. Journal of Lightwave Technology, 2000, 18(1):73-78.
[8]	ELIYAHU D, MALEKI L. Modulation response (S21) of the coupled opto-electronic oscillator//Frequency Control Symposium and Exposition.New York,USA:IEEE,2005:850-856.
[9]	YU N, SALIK E, TU M, et al. Frequency stabilization of the coupled opto-electronic oscillator//Frequency Control Symposium and Exposition. New York,USA:IEEE, 2005:857-860.
[10]	SALIK E, YU N, MALEKI L. An ultralow phase noise coupled optoelectronic oscillator [J]. IEEE Photonics Technology Letters, 2007, 19(6):444-446.
[11]	WILLIAMS C, DAVILA-RODRIGUEZ J, DELFYETT P. Noise characterization of an injection-locked COEO with long-term stabilization[J]. Journal of Lightwave Technology, 2011, 29(19):2906-2912.
[12]	WILLIAMS C, MANDRIDIS D, DAVILA-RODRIGUEZ J. Dependence of RF frequency on injected optical frequency of an injection locked coupled opto-electronic oscillator//Photonics Conference (PHO).New York,USA:IEEE, 2011:477-478.
[13]	LOH W, YEGNANARAYANAN S,PLANT J,et al. RF-amplifier-free coupled optoelectronic oscillator(COEO) //Lasers and Electro-Optics. New York,USA:IEEE,2012:1-2.
[14]	ELIYAHU D, MALEKI L. Low phase noise and spurious level in multi-loop opto-electronic oscillators//Frequency Control Symposium and PDA Exhibition Jointly with the 17th European Frequency and Time Forum. New York,USA:IEEE,2003:405-410.
[15]	REN T T, XU Ch, ZHENG Sh L,et al. Effect of dither tone-based electro-optic modulator bias control on radio-frequency signal[J]. Laser Technology, 2013, 37(6):773-776(in Chinese).
[16]	CHI J G, JIN T, CHI H,et al. Practical system for phase noise measurement of optoelectronic oscillators [J]. Journal of Optical Communication Technology, 2013, 4(4):47-50(in Chinese).
