高功率激光反射镜热畸变补偿结构设计与仿真

彭玉峰; 吴定允; 张毅; 程祖海

doi:10.3969/j.issn.1001-3806.2012.01.031

高功率激光反射镜热畸变补偿结构设计与仿真

1.
河南师范大学物理与信息工程学院, 新乡 453007;
2.
周口师范学院物理与电子工程系, 周口 466001;
3.
华中科技大学武汉光电国家实验室, 武汉 430074

作者简介: 彭玉峰(1963- ),男,教授,博士,主要从事高能激光器件、激光与物质相互作用的研究.E-mail:yufengp@sing.com.

基金项目:
国家自然科学基金资助项目(61077037);河南省基础与前沿技术计划资助项目(102300413214)
中图分类号: TN248

Simulation and structure design of a high power laser mirror with self-compensation of thermal distortion

1.
College of Physics and Information Engineering, Henan Normal University, Xinxiang 453007, China;
2.
Department of Physics &; Electronic Engineering, Zhoukou Normal University, Zhoukou 466001, China;
3.
Wuhan National Laboratory for Optoelectronics, Huazhong University Science and Technology, Wuhan 430074 China
CLC number: TN248

摘要: 为了研究激光反射镜热畸变补偿结构的设计,在分析激光腔镜热变形行为的基础上,采用优化镜体结构,提出了一种减少入射激光光斑区域镜面热畸变的途径——热畸变自补偿激光反射镜,并与普通硅镜的热变形情况进行了比较.结果表明,当反射镜反射率为98%、入射激光功率为7kW、激光照射时间分别为2s,4s和10s时,普通硅镜镜面中心与光斑边缘处的热变形之差分别为0.167μm,0.174μm和0.172μm;而热畸变自补偿激光反射镜镜面中心与光斑边缘处的热变形之差分别为0.092μm,0.052μm和0.027μm.该研究结果对提高高能激光腔镜热效应稳定性、改善高能激光光束质量具有一定参考价值.
- 光学器件 /
- 激光反射镜 /
- 热畸变 /
- 自补偿 /
- 高能激光
Abstract: A high-power laser mirror with self-compensation for thermal distortion was presented and numerically simulated on the basis of its thermal deformation behavior after optimizing its substrate structure.When 7kW laser was input in 17cm diameter,and the reflectivity of the mirror was 98%,the difference between central maximum thermal distortion and boundary thermal distortion within laser radiation region on the mirror surface for the general silicon substrate(peak valley values) was 0.167μm,0.174μm and 0.172μm respectively,under the radiation time of 2s,4s and 10s.However,the thermal distortion difference(peak valley values) of the laser mirror with self-compensation of thermal distortions was 0.092μm,0.052μm,0.027μm,respectively.The study results are useful for improving the heat-effective stability and beam quality.
- optical devices /
- laser mirrors /
- thermal distortion /
- self-compensation /
- high-power laser

[1]	PENG Y F,CHENG Z H,ZHANG Y N,et al.Temperature distributions and thermal deformations of mirror substrates in laser resonators[J].Applied Optics,2001,40(27):4824-4830.
[2]	PENG Y F,CUI J L,CHENG Z H,et al.Characteristics of thermul distortions of the laser mirror substrates filled with phase-change materials[J].Optics & Laser Technology,2006,38(8):594-598.
[3]	LI X F,ZHANG B L,LIN M,et al.Numerical analysis of thermal distortion of the mirror in space to ground laser communication links[J].Optoelectronics Letters,2005,1(3):0209-0212.
[4]	REVESZ P,KAZIMIROV A,BAZAROV I.Optical measurement of themal deformation of multilayer optics under synchrotron radiation[J].Nuclear Instruments and Methods in Physics Research,2007,A582(1):142-145.
[5]	APOLLONOV V V,BYSTROV P I,BROVAL' SKI(Î) Y A,et al.Feasibility of using liquid-metal heat carriers to cool power optics components made of porous structures[J].Soviet Journal of Quantum Electronics,1981,11(6):796-798.
[6]	YU D L,SANG F T,JIN Y Q,et al.Finite element analysis of the mirror in high-energy density laser resonator[J].High Power Laser and Particle Beams,2001,13(2):129-132 (in Chinese).
[7]	YUEN W W,FLEISHMAN R V.Parametric study of mesh enhance forced convection heat transfer for the cooling of high power density mirrors[J].Proceedings of SPIE,1989,1047:43-45.
[8]	ZHANGYN,PENGYF,CHENGZH,et al.Research of complex structure of mirror cooled by phase change[J].High Power Laser and Particle Beams,2000,12(s1):77-79 (in Chinese).
[9]	(O)ZISIK M N.Heat conduction[M].New York:Wiley,1980:1-21.
[10]	NOWINSIK J L.Theory of thermoelasticity with applications[M].Netherlands:Sijthoff & Noordhoff International Publishers,1978:261-270.
[11]	FENGZQ,BAIL,ZHANGZB,et al.Thermal deformation compensation of high-energy laser mirrors[J].Optics and Precision Engineering,2010,18(8):1781-1786 (in Chinese).
[12]	YANG Zh Q,CHEN H Q,WANG L,et al.Investigation of laser aberration compensation using an intracavity deformable mirror[J].Laser Technology,2007,31 (5):449-451 (in Chinese).
