Preparation and properties of Yb3+-doped silicate laser glass
-
摘要: 为了制备Yb3+掺杂硅酸盐激光玻璃,并对其激光特性进行分析,采用富氧气氛下的非化学气相沉积高温熔融工艺,通过Fuchbauer-Ladenburger方法,进行了理论分析和实验验证,取得了所制备硅酸盐激光玻璃的吸收光谱和荧光光谱数据。结果表明,在850nm～1100nm近红外波段为吸收区域,有一宽带吸收峰;吸收主峰位于978nm,次峰位于919nm;其荧光主峰位于1018nm,次峰位于970nm,并理论计算了Yb3+的吸收截面面积、受激发射截面面积及其荧光寿命等特征参量。这一结果对硅酸盐激光玻璃的特性分析是有帮助的,所制备的玻璃材料能够满足激光玻璃的使用要求。
-
关键词:
- 材料 /
- 激光技术 /
- Yb3+掺杂硅酸盐激光玻璃 /
- 非化学气相沉积高温熔融 /
- 吸收光谱 /
- 荧光光谱
Abstract: In order to prepare Yb3+-doped silicate laser glass and analyze its laser characteristics, based on the no-chemical vapor deposition high temperature melting process in an oxygen-enriched atmosphere, the data of the absorption and fluorescence spectra of the glass were obtained according to Fuchbauer-Ladenburger(F-L) method. It can be concluded that there are board-band absorption peaks in the absorption band of 850nm~1100nm near-infrared wavelengths. The main absorption peak is at 978nm and the sub-peak value is at 919nm respectively, the main fluorescent peak is at 1018nm with the sub-peak value at 970nm. The integrated absorption cross section, stimulated emission cross section and fluorescent lifetime of Yb3+ were calculated theoretically. This result is useful to characteristic analysis of silicate laser glass. The comprehensive test results show that they can meet the application requirements of laser glass. -
-
[1] YU H W,DUAN W T,XU M J,et al.Review of ytterbium-doped laser materials[J].Laser Optoelectronics Progress,2007(5):30-41(in Chinese).
[2] CHE J B,YANG Y P,LIU Sh,et al.Gain sum arization of Er3+/Yb3+ co-doped phosphate glass fiber amplifiers[J].Laser Technology,2006,30(1):82-85(in Chinese).
[3] JOSE N P.Super fluorescence from Yb and Yb-Er-doped phosphate llurite glass fiber[J].Optical Fiber Technology,2008,14(4):275-280.
[4] YANG J H，DAI Sh X，WEN L,et al.Spectroscopic properties of erbium-doped bismuth-based glass[J].Acta Photonica Sinica，2002,31(11):1382-1386(in Chinese).
[5] FAN T Y.Heat generation in Nd:YAG and Yb:YAG[J].IEEE Journal of Quantum Eleetronics,1993,29(6):1457-1459.
[6] MAO Y L，DENG P Zh，GAN F X，et al.Spectroscopic properties of Yb3+ in phosphate glass[J].Chinese Journal of Luminescence，2002,23(2):152-156(in Chinese).
[7] LIN A X,DAI N L,HU L L,et al.Physical and spectroscopic properties of Yb3+-doped germanosilicate glasses[J].Journal of the Chinese Ceramic Socitey，2004,32(5):620(in Chinese).
[8] QIU G M.Ytterbium-doped laser glass[J].Chinese Rare Earths,2004,25(2):73(in Chinese).
[9] WEBER W J,LYNCH J E,BLACHBURN D H,et al.IEEE Journal of Quantum Electronics,1983,19(10):1600-1608.
[10] ZOU X L,TORATANI H.Evaluation of spetroscopic properties of Yb3+-doped glass[J].Physics Review,1995,B52(22):15889-15897.
[11] TAKEBE H,MURATA T,MORINAGA K.Compositional dependence of absorption and fluorescence of Yb3+ in oxide glasses[J].Journal of the American Ceramic Society,1996,79(3):681.
[12] LAURA D D,STEPHEN A P,CHASE L L,et al.Evaluation of absorption and emission properties of Yb3+-doped crystal for laser applications[J].IEEE Journal of Quantum Electronics,1993,29(4):1179-1191.
