光子晶体光纤与普通光纤的耦合熔接

奚小明; 陈子伦; 刘诗尧; 侯静; 姜宗福

doi:10.3969/j.issn.1001-3806.2011.02.017

光子晶体光纤与普通光纤的耦合熔接

1.
国防科学技术大学光电科学与工程学院, 长沙, 410073

作者简介: 奚小明(1987- ),男,硕士研究生,主要从事光子晶体光纤方面的研究..

通讯作者: 侯静, honjing25@sina.com ;

基金项目:
教育部新世纪优秀人才计划资助项目(NCET-08-0142)
中图分类号: TN253

Coupling and fusion splicing of photonic crystal fibers with conventional fibers

1.
College of Optoelectronic Science and Engineering, National University of Defense Technology, Changsha 410073, China

Corresponding author: HOU Jing, honjing25@sina.com ;

CLC number: TN253

摘要: 为了实现光子晶体光纤与普通光纤低损耗熔接,采用优化熔接机参量和逐渐塌缩光子晶体光纤空气孔的方法,对光子晶体光纤和普通光纤熔接损耗的主要来源及普通熔接机参量的选择进行了详细的理论分析,并对光子晶体光纤和普通光纤模场直径相匹配和不匹配两种情况分别进行了熔接实验研究,取得了小于0.2dB和0.3dB的熔接损耗。结果表明,通过优化熔接机参量可以实现模场直径相匹配的光子晶体光纤与普通光纤的低损耗熔接,而模场直径不匹配的情况可以通过逐渐塌缩光子晶体光纤空气孔从而增加光子晶体光纤的模场直径的方法来实现低损耗熔接。
- 光纤光学 /
- 光子晶体光纤 /
- 普通光纤 /
- 熔接损耗 /
- 模场直径
Abstract: In order to realize low loss fusion splicing between photonic crystal fiber(PCFs)and conventional fibers,after optimizing the splicer parameters and gradually decreasing the air hole collapse of PCFs,the main source of fusion splicing loss between PCFs and conventional fibers and rules of choosing parameters of arc fusion splicer were discussed in detail.Then some experiments splicing PCFs and conventional fibers were carried out with matched and mismatched mode field diameters,and very low loss(less than 0.2dB and 0.3dB respectively)was obtained.In conclusion,low loss splicing can be achieved by optimizing the splicer parameters for matched mode field diameters,however for much mismatched mode field diameters,low splicing loss can be obtained through controlling air hole collapse of PCFs.
- fiber optics /
- photonic crystal fiber /
- conventional fiber /
- splicing loss /
- mode field diameter

[1]	WANG R X.Numerical study on the coupling of the photonic crystal fiber[J].Laser Technology,2007,31 (5):493-495(in Chinese).
[2]	WANG R X.Numerical study of splice loss of high-nonlinearity photonic crystal fibers[J].Laser Technology,2008,32 (3):302-304 (in Chinese).
[3]	ZHANG W,ZHANG L,CHEN Sh,et al.Low loss splicing experiment of high nonlinearity photonic crystal fiber and single mode fiber[J].Chinese Journal of Lasers,2006,33(10):1389-1392(in Chinese).
[4]	GUO T Y,LOU Sh Q,LI H L,et al.Low loss arc fusion splice od photonic crystal fibers[J].Acta Optica Sinica,2009,29(2):511-516(in Chinese).
[5]	YEUK L H,WEI J,JIAN J,et al.Loss analysis of single-mode fiber/photo-crystalfiber splice[J].Microwave and Optical Technology Letters,2004,40 (5):378-380.
[6]	CHONG J H,RAO M K,ZHU Y,et al.An effective splicing method on photonic crystal fiber using CO2 laser[J].IEEE Pbotonic Technology Letters,2003,15 (7):942-944.
[7]	CHONG J H,RAO M K.Development of a system for laser splicing photonic crystal fiber[J].Optics Express,2003,11 (12):1366-1370.
[8]	YABLON A D,BISE R T.Low-loss high-strength microstructured fiber fusion splices using GRIN fiber lenses[J].IEEE Photonic Technology Letters,2005,17(1):118-120.
[9]	NAKAJIMA K,HOGARI K,ZHOU J,et al.Hole assisted fiber design for small bending and splice losses[J].IEEE Photonic Technology Letters,2003,15 (12):1737-1739.
[10]	KERBAGE C,HALE A,YABLON A,et al.Integrated all-fiber variable attenuator based on hybrid microstructure fiber[J].Applied Physics Letters,2001,79(19):3191-3193.
[11]	WANG Y P,BARTELT H,BRUECKNER S,et al.Splicing Gedoped photonic crystal fibers using commercial fusion splicer with default discharge parameters[J].Optics Express,2008,16 (10):7258-7263.
[12]	LEON-SAVAL S G,BIRKS T A,JOLY N Y,et al.Splice-free interfacing of photonic crystal fibers[J].Optics Letters,2005,30(13):1629-1631.
[13]	XIAO L,DEMOKAN M S,JIN W,et al.Fusion splicing photonic crystal fibers and conventional single-mode fibers:microhole collapse effect[J].Journal of Lightwave Technology,2007,25 (11):3563-3568.
[14]	BOURLIAGUETB,PARÉ C,ÉMOND F,et al.Microstructurod fiber splicing[J].Optics Express,2003,11 (25):3412-3417.
[15]	XIAO L,JIN W,DEMOKAN M S.Fusion splicing small-core photonic crystal fibers and single-mode fibers by repeated arc discharges[J].Optics Letters,2007,32(2):115-117.
[16]	FRAZAO O,CARVALHO J P,SALGADO H M.Low-loss splice in a microstructured fibre using a conventional fusion splicer[J].Microwave and Optical Technology Letters,2005,46(2):105-109.
[17]	LAGSGAARD J,BJARKLEV A.Reduction of coupling loss to photonic crystal fibers by controlled hole collapse:a numerical study[J].Optics Communications,2004,23(7):431-435.
[18]	WANGYB,CHENZL,HOU J,et al.Effectively increasing mode field diameter of photonic crystal fibers[J].High Power Laser and Particle Beams,2010,22(7):1491-1494(in Chinese).
