Design of a beam expander with a single aspheric lens
-
摘要: 为了设计单个椭球面缩束(扩束)透镜,采用全面学习策略的粒子群算法作为设计方法,依据光线折射定律矢量形式所表征的椭球面折射特性进行了理论分析,得到了用全面学习策略的粒子群优化算法设计单个椭球面缩束(扩束)透镜的适应度数据公式,设计出了线度小于170mm缩束14.16倍的单个椭球面缩束透镜,并用光线追迹方法模拟了缩束或扩束过程。结果表明,单个椭球面透镜可以起到缩束或者扩束作用,全面学习策略的粒子群算法可用于椭球面缩束透镜的设计。这一结果对于简化扩(缩)束系统结构、设计出适应于不同要求的单个扩(缩)束透镜是有帮助的。Abstract: In order to design a beam expander or beam compressor with a single ellipsoidal lens, the comprehensive learning strategy particle swarm algorithm was introduced. The refraction characteristics of an ellipsoidal surface expressed by the vector form of refraction law was theoretically analyzed. Fitness data formula in the comprehensive learning strategy particle swarm optimizer was gotten. A single ellipsoidal beam-expanding lens with length less than 170mm and shrinkage rate of 14.16 was designed. The process of beam-shrinking or beam-expanding was simulated by using the ray tracing method. Simulation results show that a single ellipsoidal lens can play the role in compressing beam or expanding beam, and the comprehensive learning particle swarm algorithm can be applied to the design of beam expanders/compressors. The results is helpful in simplifying beam expanding/compressing systems and designing a single expanding/compressing beam lens to meet different requirements.
-
Keywords:
- optical design /
- expanding beam /
- aspheric lens /
- particle swarm algorithm
-
-
[1] LIU H B,AN Zh Y,GAO Y H, et al. System design of a varifocal beam expander[J]. Journal of Changchun University of Science and Technology (Natural Science Edition), 2010, 33(4):43-45(in Chinese).
[2] ZHENG X,ZUO Ch Ch,ZHOU X Q. Optical route simulation of two-photon polymerization[J]. Laser Technology, 2015,39(3):325-328(in Chinese).
[3] FAN L N, ZHU A M, LIU L, et al. Optical design of laser beam expanding telescope[J]. Infrared,2007, 28(8):20-22(in Chinese).
[4] HE T, WANG Zh R,YUAN G H. Fan-shaped semiconductor micro-ring lasers based on an elliptical reflector mirrors[J]. Laser Technology, 2014, 38(1):114-118(in Chinese).
[5] ZHAO Y N, WANG X, XIANG Y. Design of catadioptric variable focus beam expanding optical system[J]. Journal of Changchun University of Science and Technology (Natural Science Edition), 2012, 35(1):46-48(in Chinese).
[6] GUO Y X, LI Y C,LIANG T M, et al. Optical design of the uncoaxial three-mirror system with wide field of view[J]. Acta Optica Sinica, 2010, 30(9):2680-2683(in Chinese).
[7] YU D Y, TAN H Y. Engineering optics[M]. 3rd ed. Beijing:China Machinery Industry Press, 2011:6(in Chinese)
[8] QIAO L, YANG Y N. Experimental research of laser wireless power transmission efficiency[J]. Laser Technology, 2014, 38(5):590-594(in Chinese).
[9] YE J F, GAO Zh Sh, YE H Sh, et al. Near-infrared a focal laser beam expanding system with large zoom ratio[J]. Optics and Precision Engineering, 2013, 21(5):1129-1136(in Chinese).
[10] HUANG Sh, DENG L M, YANG H, et al. Homogenization design of laser diode based on ZEMAX[J]. Laser Technology, 2014, 38(4):522-526(in Chinese).
[11] HUA Q. Aberration correction of a single aspheric lens with particle swarm algorithm[J]. Optics Communications, 2012, 285(13/14):2996-3000.
[12] LIANG J J, QIN A K, SUGANTHAN P N, et al. Comprehensive learning particle swarm optimizer for global optimization of multimodal functions[J]. IEEE Transactions on Evolutionary Computation, 2006,10(3):281-295.
[13] MARCUSE D. Light transmission optics[M]. New York,USA:Van Nostrand Reinhold Co., 1982:150-155.
[14] ZHOU B K, GAO Y Zh, CHEN T R, et al. Principles of lasers[M]. 7th ed. Beijing:National Defense Industry Press, 2014:11(in Chinese).
[15] ZHANG F Sh. Numerical computation for propagation of Gaussian beam through aspheric system[J]. Acta Optica Sinica, 2008, 28(1):179-183(in Chinese).
