Time division multiplexing array of fiber laser hydrophone using optical switch
-
摘要: 为了降低传感器系统的成本及体积,利用光纤激光传感单元的特性,采用光开关选通的光纤激光水听器时分复用技术,构建了实用的基于光开关的4元光纤激光水听器时分阵列。进行了理论分析和实验验证,分析了使用光开关选通的光纤激光水听器时分复用阵列方案的选通脉宽和损耗,指出了各通道光脉冲对干涉信号的采样率的限制因素。结果表明,光开关选通的光纤激光水听器时分阵列可以很好地完成复用信号的采集和复用,实验中4元时分复用水听器相邻通道的串扰为-17dB。Abstract: In order to reduce the cost and the size of a sensing system, a 4-element fiber laser hydrophone time division multiplexing array was established by using high-speed optical switches based on the characteristics of fiber laser sensing elements. The selective pulse width and the loss of the time division multiplexing array were analyzed after theoretical analysis and experimental verification. Because of time delay of the interferometer and switch speed of the optical switches, sampling frequency was limited. The acoustic detecting experiments show that the multiplexing signal can be acquired and demutiplexed correctly. The crosstalk between adjacent channels of the 4-element fiber laser hydrophone array is -17dB.
-
Keywords:
- sensor technique /
- hydrophone array /
- time division multiplexing /
- optical switch /
- fiber laser
-
-
[1] LI D, ZHOU J H, QU K L, et al. Anti-wave demodulation method for acousto-optic coupling fiber hydrophones on the water surface[J]. Laser Technology, 2015,39(1):1-5(in Chinese).
[2] KERSEY A D, KOO K P, DAVIS M A. Fiber optic Bragg grating laser sensors[J].Proceedings of the SPIE,1994,2292:102-112.
[3] KOO K P, KERSEY A D. Bragg grating based laser sensor systems with interferometric interrogation and wavelength division multiplexing[J].Journal of Lightwave Technology, 1995, 13(7):1243-1249.
[4] HILL D J, NASH P J, JACKSON D A, et al. A fiber laser hydrophone array[J].Proceedings of the SPIE,1999,3860:55-66.
[5] HILL D J, HODDER B, FREITAS J D. DFB fibre-laser sensor developments[J].Proceedings of the SPIE,2005,5855:904-907.
[6] SCOTT F, ALEXEI T, MARK M, et al. A fibre laser hydrophone[J].Proceedings of the SPIE,2005,5855:627-630.
[7] SCOTT F, ALEXEI T, MARK M, et al. A 16 channel fibre laser sensor array[C]//Australian Conference on Optical Fibre Technology 2006. Melbourne, Australia:Australian Optical Society, 2006:40-42.
[8] STEVEN G, SCOTT F, JOHN V, et al. Demonstration of a DFB fibre laser hydrophone seabed array in jervis bay[J].Proceedings of the SPIE,2009,7503:75034L.
[9] KULLANDER E, VAHLBERG C. Towed a thin and lightweight fibre optic towed array sonar[J]. Archives of Acoustics, 2005,30(4):91-94.
[10] XU H, WANG C, PENG G D, et al. A distributed feedback fiber laser hydrophone with high sensitivity and flat frequency response[J]. Shandong Science, 2013,26(4):46-50(in Chinese).
[11] ZHANG W T, HUANG W Z, LUO Y B, et al. Field test of the flow noise of fiber laser hydrophone array[J].Proceedings of the SPIE,2014,9157:91579P.
[12] ZHANG F X, ZHANG X L, WANG L J, et al. Study on the frequency response of static pressure compensated fiber laser hydrophone-theory and finite element simulation[J].Proceedings of the SPIE,2014,9157:91571I.
[13] GU H C, HUANG J B, YU H B, et al. A 4-element fiber laser hydrophone towed linear array[J].Proceedings of the SPIE,2014,9297:92972Y.
[14] ZHAO Z Q,SULEYMAN D M. Improved demodulation scheme for fiber optic interferometers using an asymmetric 33 coupler[J]. Journal of Lightwave Technology, 1997, 15(11):2059-2068.
[15] CHEN D S, XIAO L, CUI J, et al. Analysis of 33 coupler demodulation method for optical fiber interferometer and polarization fading[J]. Journal of OptoelectronicsLaser, 2007, 18(5):523-525(in Chinese).
[16] QI L Z, XIAO H, LI F, et al. Study of polarization-insensitive fiber optic interferometers for wavelength demodulation[J]. Laser Infrared, 2008, 38(3):259-262(in Chinese).
[17] GU H C, HUANG J B, YUAN B C, et al. Fiber laser acoustic pressure sensing system based on interferometric demodulation technique[J]. Opto-Electronic Engineering, 2008, 35(12):73-77(in Chinese).
[18] ZHANG N. Optical heterodyne and time division multiplexing technology in large-scale fiber optic hydrophone array[D]. Changsha:National University of Defense Technology, 2007:8-9(in Chinese).
[19] JIN Z G, HU Y M, LUO H. Time division multiplexing of optical fiber hydrophone using optical switch[J]. Semiconductor Optoelectronics, 2003, 24(1):63-65(in Chinese).
[20] TAN B, HUANG J B. Design about a novel encapsulation structure of DFB fiber laser hydrophones[J].Proceedings of the SPIE,2014,9233:92330X.
[21] LI J T. Analyses of crosstalks and noise in multiplexing array of fiber optic hydrophone[D]. Changsha:National University of Defense and Technology, 2005:36-37(in Chinese).
[22] GU H C, HUANG J B, LI R Zh, et al. Analysis of the channel crosstalk in multiplexing system of the fiber laser sensors[J].Proceedings of the SPIE,2014,9297:92972X.
-
