Research on adjustable high power high pulse-repetition-frequency compact LD power supply
-
摘要: 为了获得高功率、高重频半导体激光脉冲,设计了一种体积小、重量轻、造价低的纳米级大功率半导体激光器驱动电源。采用改进的单稳态触发器产生窄脉冲,经放大后驱动快速开关MOSFET获得大电流窄脉冲;电源脉冲电流驱动能力0A～80A,脉冲上升时间2.8ns,下降时间3.8ns,脉冲宽度5ns～500ns范围内可调,最小5.2ns,重复频率可达200kHz。用该电源实验测试了激光波长为905nm的半导体激光器,在重复频率为10kHz时,激光脉冲峰值功率达到70W以上。结果表明,采用窄脉冲驱动MOSFET可以得到高重复频率10ns以内的大电流窄脉冲,可以驱动大功率半导体激光器,若驱动100A以上的激光器需进一步研究。Abstract: In order to obtain high power and high pulse-repetition-frequency(PRF) laser pulse,a nanosecond nanosecond-level laser diode driver with advantages of small size,light weight and low cost was designed.The narrow pulse,which was generated by an improved mono-stable circuit,was amplified to high current narrow pulse to drive metal-oixde-semiconducor field-effect-transistor(MOSFET)switch for narrow pulse of high current.The output current of the driver was 0A~80A;the rise time of the pulse was 2.8ns;the fall time was 3.8ns;the pulse width can could be adjusted between 5ns and 500ns;the narrowest with the minimal pulse width can be of 5.2ns;and the PRF pulse repetition frequency was up to 200kHz.When this power supply was used for a 905nm laser diode,its peak laser power was up to 70W at PRF of 10kHz.The results show that the narrow pulse can be used to drive MOSFET to obtain 10ns or narrower pulse with high PRF and current,and this driver can completely meet the demand for driving high power laser diode.Further research is necessary for 100A or higher drive current.
-
-
[1] YANKOV P,TODOROV D.A high power high frequency laser diodes driver[C]//27th International Spring Seminar on Electronics Technology:Meeting the Challenges of Electronics Technology Progress,2004,Bankya,Bulgaria.Piscataway,N J,USA:IEEE,2004: 451-452.
[2] ZHANG H M,LIU X S,LU X Y,et al.Design of laser diode driver with high peak current and narrow pulse width[J].Semiconductor Optoelectronics,2009,30(2):313-315(in Chinese).
[3] NI X P,YU Z Q,HUANG Y,et al.Design of driver circuit for high speed of nanosecond pulsed diode laser driver[J].Guangxi communication Technology,2010(4):39-42(in Chinese).
[4] CHEN W,CAI X P,LI W,et al.Design of semiconductor laser pulse driver based on avalanche transistors[J].OEM Information, 2010,27(2):32-35(in Chinese).
[5] MING Q,MEI X L,LI C Q.Design of driver circuit for wide range continuous and pulse LD[J].Electronic Design Engineering,2010, 18(6):183-185(in Chinese).
[6] YAN B.Analysis of pulsed laser diode driver circuit[J].Optics& Optoelectronic Technology,2008,6(4):1-3(in Chinese).
[7] SUN D G,TANG H F.Study on the PWM driver circuit of LD for laser fuze[J].Laser Technology,2007,31(2):217-219(in Chinese).
[8] LIU X Sh,LIN J L,ZHANG H M,et al.The study of nanosecond pulsed diode laser driver[J].Laser Technology,2006,30(4):445-448(in Chinese).
[9] ZHANG S Q,LOU Q H,ZHOU J,et al.Design of drive circuit for continuously adjustable ns pulse LD[J].Laser Technology,2008,32 (4):396-398(in Chinese).
[10] ZHU N,LIN J L,WANG G J,et al.Application of avalanche transistors in nanosecond pulse driver[J].Optoelectronic Technology& Information,2005,18(6):29-32(in Chinese).
[11] CHEN W,MIAO Q M,SUN F,et al.Design of high current narrow width pulsed power supply of laser diode[J].High Power Laser and Particle Beams,2010,22(6):1223-1228(in Chinese).
