选区激光熔化直接成型个性化舌侧托槽的研究

孔卫东; 王淑范; 王迪; 卢建斌; 杨永强

选区激光熔化直接成型个性化舌侧托槽的研究

1.
暨南大学附属第一医院口腔科广州 510010;
2.
华南理工大学医院口腔科广州;
3.
华南理工大学机械与汽车工程学院广州 510640

作者简介: 孔卫东(1965- ),男,副教授,主要研究领域为口腔正畸学及口腔材料.E-mail:tkongwd@jnu.edu.cn..

通讯作者: 孔卫东, tkongwd@jnu.edu.cn ;

基金项目:
广东省教育部产学研结合基金重点资助项目(2010A090200072);广东省自然科学基金资助项目(8151063201000071);中央高校基本科研业务费专项基金资助项目(21609503)
中图分类号: TN249;TG665

Preliminary study on direct manufacturing of customized lingual brackets by selective laser melting

1.
Department of Stomatology, the First Affiliated Hospital of Jinan University, Guangzhou 510010, China;
2.
Department of Stomatology, Hospital of South China University of Technology, Guangzhou 510640, China;
3.
School of Mechanical and Automotive Engineering, South China University of Technology, Guangzhou 510640, China

Corresponding author: KONG Wei-dong, tkongwd@jnu.edu.cn ;

CLC number: TN249;TG665

摘要: 为了探讨应用选区激光熔化快速成型技术直接制造个性化金属舌侧托槽的可行性,采用3维激光扫描仪采集与重建牙颌模型数据,并以该数字模型为基础,应用3维软件进行了个性化舌侧托槽的CAD设计,再通过自主研发的选区激光熔化快速成型机直接制造出个性化金属舌侧托槽,并对托槽的直接成型质量进行了理论分析和实验验证。结果表明,3维激光扫描仪获得的牙颌模型数据可以满足个性化舌侧托槽设计要求;应用选区激光熔化技术能够制造出与实际牙颌模型相一致的个性化舌侧托槽,取得了个性化前牙槽沟宽度为0.471mm±0.009mm数据,前牙槽沟宽度CAD设计值为0.460mm,两者间没有统计学上的差异(p0.05)。这一结果对选区激光熔化技术直接制造个性化金属舌侧托槽的实际应用是有帮助的。
- 激光技术 /
- 选区激光熔化 /
- 个性化设计与制造 /
- 舌侧托槽
Abstract: In order to investigate the feasibility of direct manufacturing customized lingual brackets by selective laser melting,firstly,a 3-D scanner was used to acquire and reconstruct teeth model,which was based on the customized lingual brackets designing with 3-D software;then customized metal lingual brackets were directly manufactured with a self-developed selective laser melting apparatus;finally the slot width of the bracket on front teeth was measured.The analysis shows that the teeth model obtained from the three dimensional laser scanner can meet the requirements for customized lingual brackets designing,and customized metal lingual brackets that can well fitted with teeth model can be produced precisely by selective laser melting process.Compared with the designed value 0.460mm on CAD model,the slot width of the front teeth was measured 0.471mm±0.009mm.The research proves it is feasible to manufacture precise and well fitted customized metal lingual brackets by means of selective laser melting technique.
- laser technique /
- Sweletive laser Melting /
- customizes design manufacturing /
- lingual bracket

[1]	,ERASENTHIRAN P,HOPKINSON N.High density selective laser melting of waspaloy[J].Journal of Materials Processing Technology,2008,195(1/3):77-87.
[2]	KRUTHA J P,FROYENB L,van VAGERNBERGHA J.Selective laser melting of iron-based powder[J].Journal of Materials Processing Technology,2004,149(1/3):616-622.
[3]	SHAPACK N,GERON S,FLORIS I.Bracket placement in lingual vs labial systems and direct vs indirect bonding[J].Angle Orthodontist,2007,77(3):509-517.
[4]	PAULS A H.Therapeutic accuracy of individualized brackets in lingual orthodontics[J].Journal of Orofacial Orthopedics,2010,71(5):348-361.
[5]	WU W H,YANG Y Q,WANG H W,et al.Research on direct rapid manufacturing of 316L fine metal part using fiber laser[J].Laser Technology,2009,33 (5):486-489 (in Chinese).
[6]	MORGAN R,SUTCLIFFE C J,O'NEILLW.Density analysis of direct metal laser re-melted 316L stainless steel cubic primitives[J].Journal of Materials Science,2004,39(4):1195-1205.
[7]	WIECHMANN D.A new bracket system for lingual orthodontic treatment[J].Journal of Orofacial Orthopedics,2002,63(3):234-245.
[8]	WIECHMANN D,RUMMEL V,THALHEIM A.Customized brackets and archwires for lingual orthodontic treatment[J].American Journal of Orthodontics and Dentofacial Orthopedics,2003,124(5):593-599.
[9]	DING Y,XU B H.Characteristics and applications of personalized lingual orthodontic.technology[J].Chinese Journal of Orthodontics,2007,14(3):138-139(in Chinese).
[10]	HE X R,YANG Y Q,KONG W D,et al.Direct manufacturing of customized crowns and fixed bridge by selective laser melting[J].Laser Technology,2010,34(1):1-4 (in Chinese).
[11]	YANG Y Q,HE X R,HUANG W H,et al.Direct manufacturing of customized orthopedics surgery orienting model by selective laser melting[J].Chinese Journal of Lasers,2009,36 (12):2460-2464(in Chinese).
