剩余振幅调制对波长调制光谱信号线型的影响

伍昂; 吴尚谦; 蔡彦; 董跃辉; 翟维

剩余振幅调制对波长调制光谱信号线型的影响

1.
昆明理工大学理学院昆明 650093

作者简介: 伍昂(1986- ),男,硕士研究生,主要从事基于TDLAS的大气痕量气体检测方法的研究..

通讯作者: 吴尚谦, wusq@kmust.edu.cn ;

中图分类号: O433.5⁺1

Effect of RAM on WMS signal line shape

1.
Faculty of Science, Kunming University of Science and Technology, Kunming 650093, China

Corresponding author: WU Shang-qian, wusq@kmust.edu.cn ;

CLC number: O433.5⁺1

摘要: 在基于可调谐二极管激光吸收光谱技术的痕量气体检测中,波长直接调制时剩余振幅调制也会伴随发生,并对检测信号的线型和系统噪声产生严重影响。为了探讨剩余振幅调制对波长调制光谱二次谐波信号线型的影响,采用同时考虑振幅调制和波长调制两种影响因素的计算方法,理论分析出二次谐波信号的计算公式,与仅考虑波长调制的信号计算方式进行同条件线型计算比对,取得了二次谐波信号基线和正负峰值随剩余振幅调制的变化数据。结果表明,剩余振幅调制的大小对检测信号的线型和信号基线有直接影响,采用这种方法计算得出的二次谐波信号线型更贴近实际检测。
- 光谱学 /
- 可调谐二极管激光吸收光谱 /
- 波长调制光谱 /
- 二次谐波检测 /
- 剩余振幅调制
Abstract: In the detection of trace gas based on tunable diode laser absorption spectroscopy(TDLAS),residual amplitude modulation(RAM) might happen simultaneously when wavelength modulation is performed directly by input current.This RAM will affect line-shape of measurement signal and system noise.In order to study the influences of RAM on the line-shape of the second harmonic signal of wavelength modulation spectroscopy(WMS),a calculation method of the second harmonic signal was put forward simultaneously considering amplitude modulation and frequency modulation(AM-FM) factor.After analyzing the method,the corresponding expression was derived.Quantitative calculation results were compared between AM-FM method and traditional FM method.The baseline,positive and negative peak of the second harmonic signal were obtained.The results show that the RAM has direct influences on detection signal line shape and signal baseline.The signal line shape calculated with the AM-FM method more close to detected results.
- spectroscopy /
- tunable diode laser absorpiton spectroscopy /
- wavelength modulation spectroscopy /
- second-harmonic detection /
- residual amplitude modulation

[1]	CHEN H,ZHOU F X,XU Zh,et al.An integrated control system for carbon monoxide detection,emission and recycling[J].Laser Technology,2011,35 (3):360-363 (in Chinese).
[2]	ZHOU N,LI L S,CAO M D,et al.Development of 1650nm DFB lasers applied in trace methane detection[J].Laser Technology,2011,35(3):289-292(in Chinese).
[3]	LINS B,ZINN P,ENGELBRECHT R,et al.Simulation based comparison of noise effects in wavelength modulation spectroscopy and direct absorption TDLAS[J].Applied Physics,2010,B100(2):367-376.
[4]	REID J,IABRIC D.Second-harmonic detection with tunable diode lasers:comparison of experiment and theory[J].Applied Physics,1981,B26(3):203-210.
[5]	OLSON M L,GRIEBLE D L,GRIFFTTHS P R.Second derivative tunable diode laser spectrometer for line profile determination Ⅰ.Theory[J].Applied Spectroscopy,1980,34(1):50-56.
[6]	ARNDT R.Analytical line shapes for Lorentzian signals broadened by modulation[J].Journal of Applied Physics,1965,36(8):2522-2524.
[7]	GEHRTZ M,BJORKLUND G C,WHITTAKER E A.Quantum-limit ed laser frequency-modulation spectroscopy[J].Journal of the Optical Society of America,1985,B2(9):1510-1526.
[8]	CARLISLE C B,COOPER D E.Tunable diode laser frequcncy modu lation spectroscopy through an optical fiber:high-sensitivity detection of water vapor[J].Applied Physics Letters,1990,56 (9):805-807.
[9]	CHEN D,JIA Zh L.Signal analysis of tunable diode laser based wavelength modulation spectroscopy[J].Journal of Atmospheric and Environmental Optics,2008,3(3):193-198(in Chinese).
[10]	AXNER O,KLUCZYNSKI P,LINDBERG A M.A general non-complex analytical expression for the nth Fourier component of a wavelength-modulated Lorentzian lineshape function[J].Journal of Quantitative Spectroscopy & Radiative Transfer,2001,68 (3):299-317.
[11]	SILVER J A.Frequency-modulation spectroscopy for trace species detection:theory and comparison among experimental methods[J].Applied Optics,1992,31 (6):707-717.
[12]	WU Sh Q,KIMISHIMA T,KUZE H,et al.Efficient redution of fringe noise in trace gas detection with diode laser multipass absorption spectroscopy[J].Japanese Journal of Applied Physics,2000,39(7A):4034-040.
[13]	LEHTH W.High frequency heterodyne spectroscopy with currentmodulated diode lasers[J].IEEE Journal of Quantum Electronics,1984,20(9):1045-1050.
[14]	GEHRTZ M,LENTH W,YOUNG A T,et al.High-frequency-modulation spectroscopy with a lead-salt diode lasers[J].Optics Letters,1986,11 (3):132-134.
[15]	LIANG B,ZHU Y,BAO W Y.Study on the compensation technology of remaining light intensity modulation in TDLAS[J].Chinese Journal of Sensors and Actuators,2010,23 (7):939-943 (in Chinese).
