基于双光楔的激光模拟训练系统弹道模拟研究

详细信息

Study on ballistic trajectory simulation of a laser simulation training system based on dual-wedge

th Research Institute of General Staff Department, Chinese People's Liberation Army, Nanjing 210016, China

摘要: 为了实现激光模拟训练系统的弹道模拟,以双光楔光束偏转性质为基础,研究了通过控制双光楔的旋转角度来控制激光光轴的偏转,并根据光折射理论计算推导了双光楔角度控制方程。结果表明,模拟训练系统激光光束指向精度高于1mrad,能够满足实际需要。该系统可用于坦克等直瞄重武器的实兵对抗训练。
- 激光技术 /
- 模拟训练 /
- 双光楔 /
- 弹道模拟
Abstract: In order to actualize ballistic trajectory simulation in a laser simulation training system, on the basis of the beam deflexion character of dual-wedge, the laser beam was deflected by control turning angle of the dual-wedge. The formula for controlling the turning angle of dual-wedge was also deduced from the optical ray refraction theorem. The experimental results indicate that the laser beam pointing accuracy of the system is higher than 1mrad. This system can be used for force-on-force engagement training of direct heavy weapons such as tanks.
- laser technique /
- simulation training /
- dual-wedge /
- ballistic trajectory simulation

[1]	CONARED H.The light brigade:lasers provide the edge in training and control[J].Photonics Spectra,1994,28(6):76-81.
[2]	LAWRENCE J D,DAVID J P.Combat simulation in USA army training and testing[C] //Proceedings of the 1996 Winter Simulation Conference.Washington DC,USA:IEEE Computer Society,1996:896-902.
[3]	FU Z X.The design of 57mm anti-craft gun type 59 laser signal shooting training system[D].Dalian:Dalian University of Technology,2007:4-17(in Chinese).
[4]	ZHAO J J,HOU Y D.Design of computer simulation system for Archibald firing training[J].Laser Technology,2003,27(6):567-568(in Chinese).
[5]	ZHU J,ZHAO Y S,ZHANG W J,et al.Design of laser simulation training system[J].Mechanical Engineering & Automation,2006,4(2):61-63(in Chinese).
[6]	WEI Z C,XIONG Y W,MO W,et al.Analysis for refractive property of rotary dual-wedge prism system and 2-D scanning trace[J].Journal of Applied Optics,2009,30(6):939-943(in Chinese).
[7]	DING X C,KUANG D B.Theoretic analysis of 2-D beam steering with dual-wedge[J].Journal of Infrared and Millimeter Waves,1992,11(1):53-58(in Chinese).
[8]	HE L,YUAN J H,LI Z,et al.Design of high-precision angle generator with double optical wedges[J].Opto-electronic Engineering,2002,29(2):46-49(in Chinese).
[9]	GAO F W,LI J X.Applied optics[M].Beijing:People's Liberation Army Press,1986:5(in Chinese).
