扫描速率对激光熔覆层组织及耐蚀性的影响
Effect of laser scanning speeds on the microstructure and corrosion resistance of laser cladding layers
-
摘要: 为了研究激光扫描速率对镍基熔覆层组织及耐蚀性能的影响,采用喷涂预置涂层与不同扫描速率下激光重熔工艺在Q235低碳钢表面制备了镍基合金熔覆层,利用光学显微镜与扫描电镜对熔覆层表面宏观形貌和微观组织形貌进行了观察,利用显微硬度计和电化学腐蚀法对熔覆层显微硬度与耐蚀性进行了测定与分析。结果表明,其它条件不变,随着激光扫描速率的增加,熔覆层组织更加致密、均匀,晶粒愈发细小,并且白亮枝晶增多,枝晶间的共晶减少;由于晶粒细化等作用,使得熔覆层的平均显微硬度与耐蚀性能均得到了显著提高;其中,以激光功率为3kW、扫描速率为6mm/s、光斑直径为3mm等参量下得到的熔覆层组织及性能最优。这些结果对合理选取激光熔覆工艺参量以达到最佳熔覆效果是有帮助的。Abstract: Ni-based alloy coating was prepared on the Q235 steel by thermal spraying and laser remelting process at different scanning speeds,in order to study the effect of laser scanning speeds on the microstructure and corrosion resistance of laser cladding layers.The surface macro-morphology and microstructure were observed with an optical microscope(OM)and a scanning electronic microscope(SEM),and the micro-hardness and corrosion resistance were measured and analyzed with the hardness tester and electrochemical corrosion method.The results show that the microstructure becomes dense and even and the grains become tiny,while the amount of the white-bright dendrites increase and the eutectic compounds between the dendrites reduce with laser scanning speeds increasing.In addition,the micro-hardness and corrosion resistance greatly increase due to grain refinement and so on.As a result,the optimum technological parameters are 3kW in laser power,6mm/s in laser scanning speed and 3mm in beam diameter for the Ni-based alloy cladding layer preparation.The result is expected to provide practical value for selecting reasonable laser cladding technological parameters to achieve optimal performance of the cladding layer.
-
Key words:
- laser technique /
- laser cladding /
- Ni-based alloy /
- laser scanning speed /
- microstructure /
- corrosion resistance
-
[1] QIAN M G.The manual of surface technology and applications[M].Beijing:Machinery Industry Press,1998:656-682(in Chinese). [2] YUAN Q L,FENG X D,CAO J J,et al.Research progress on laser cladding technique[J].Materials Review,2010,24(2):112-116(in Chinese). [3] AMITESH K,SUBHRANSU R.Effect of three-dimensional melt pool convection on process characteristics during laser cladding[J].Computational Materials Science,2009,46 (2):495-506. [4] GAO L L,BIAN X F,TIAN Y Sh,et al.Effect of Co on micrestructure and intedacial properties of Fe-based laser cladding[J].Journal of Iron and Steel Research,2009,16(4):84-88. [5] CHEN H H,XU C Y,CHEN J,et al.Microstructure and phase transformation of WC/Ni60B laser cladding coatings during dry sliding wear[J].Wear,2008,264(7/8):487-493. [6] KNUT P.Analytical model of the catchment efficiency in high speed laser cladding[J].Sudane and Coatings Technology,2009,204 (3):366-371. [7] YANG X Y,PENG X,CHEN J,et al.Effect of a small increase in the Ni content on the properties of a laser surface clad Fe-based alloy[J].Applied Surface Science,2007,253 (9):4420-4426. [8] FENG X D.Microstructure and properties of Ni-based alloy by laser cladding and thermal spraying[J].Heat Treatment Technology and Equipment,2010,31 (1):28-31 (in Chinese). [9] QIU X W,LI G,REN X,et al.Influence of scanning speed on microstructure and properties of Ni based laser cladding coating[J].Rare Metal Materials and Engineering,2009,38 (s1):325-327 (in Chinese). [10] XIONG Zh,CHEN G X,ZENG X Y.Effects of process variables on interfacial quality of laser cladding on aeroengine blade material GH4133[J].Journal of Materials Processing Technology,2009,209(2):930-936. [11] SONG Ch W,LI M X.Effect of nano-CeO2 on the microstructure and properties of laser clad nickel-based alloy coating[J].Laser Technology,2006,30(3):228-231 (in Chinese). [12] MIAO K Z,LOU B Y.Corrosion resistance of magnesium alloy and epoxy polyurethane coating system[J].Journal of Materials Protection,2009,42(4):1-4(in Chinese). [13] TIAN F J,LIU W J,SHANG X F.Study on Ni60A ceating an copper by laser cladding[J].Heat Treatment of Metals,2008,33(12):35-37 (in Chinese). [14] XUE Zh F,YE H,WANG B,et al.Effect of scanning speed on structure and properties of laser cladding of 45 steel[J].Journal of Chongqing Institute of Technology(Natural Science Edition),2009,23 (3):48-51 (in Chinese). -
