采用可调谐激光器提高光纤延迟线精度的研究

详细信息

Improvement on optical fiber delay lines precision based on tunable laser

Key Laboratory of Broadband Optical Fiber Transmission and Communication Networks, University of Electronic Science and Technology of China, Chengdu 610054, China

摘要: 为了提高一种3bit可变光纤延迟线的延时精度,提出一种采用可调谐激光器作为系统光源的技术,利用光纤的材料色散特性即光纤的折射率随传输波长变化而改变的特点,来改变延时光纤中信号存储的时间,从而达到提高光纤延迟线延时精度的目的。仿真结果表明,采用该种技术的光纤延迟线系统,平均延时误差从4.1ps下降到了1.3ps,延时精度得到了显著提高。
- 光数据存储 /
- 光纤延迟线 /
- 可调谐激光器 /
- 材料色散 /
- 延时精度
Abstract: In order to improve the precision of a 3bit variable optical fiber delay line,a new technology using a tunable laser as the lighting source of the delay system is proposed based on the characteristics of optical fiber's material dispersion that the refraction index of optical fiber changes along with the difference of transmitting wavelength.At the same time,the period of optical signal storage in delay lines is also altered and the delay precision of optical fiber delay lines is improved.The simulation results indicate the mean delay error decreases from 4.1ps to 1.3ps,and the delay precision of the 3bit optical fiber delay line is remarkably improved by using this new technology.
- optical data storage /
- optical fiber delay line /
- tunable laser /
- material dispersion /
- delay precision

[1]	KEISER G.Optical fiber communications[M].3rd ed,Beijing:Publishing House of Electronics Industry,2002.84～86 (in Chinese).
[2]	CAMPILLO A L,FUNK E E,TULCHINSKY D A et al.Wavelengthdivision-multiplexed analog-delay line[J].IEEE Journal of Lightwave Technology,2004,22 (2):440～447.
[3]	YEGNANARAYANAN S,JALALI B.Wavelength-selective true time delay for optical control of phased-array antenna[J].IEEE Photonics Technology Letters,2000,12 (8):1049～1051.
[4]	WU Ch Q.The theory of optical waveguide[M].Beijing:Tsinghua University Press,2005.81～84(in Chinese).
[5]	ZHU Zh,CHEN L Y,LI H et al.Wavelength stabilization scheme for tunable laser diode based on temperature feedback[J].Laser Technology,2005,29(1):18～20(in Chinese).
[6]	WANG H,WANG P,YU H.Optical fiber communications[M].Beijing:Publishing House of Electronics Industry,2004.186～194 (in Chinese).
[7]	SHI Ch Zh,LIAO Y B,LAI Sh R.Nonlinear properties of chalcogenide fibers and their application to all-optical switching[J].Laser Journal,2001,20(5):1～4(in Chinese).
[8]	LI M,LIAO Y B,SHI Ch Zh.Dispersion characteristics of single mode As2S3 fiber[J].Acta Photonica Sinica,2000,29 (2):171～173 (in Chinese).
