Study on thermal conductivity of the YAG and GGG laser crystal
-
摘要: 为了研究不同掺杂YAG和GGG激光晶体的导热特性,采用瞬态脉冲法测量了273K~393K温度范围内自己生长的不同掺杂YAG和GGG激光晶体的热导率,并建立了实验样品温度场模型,推导出热导率对温度的函数关系,得到晶体热导率随温度变化曲线,这与实验测量结果基本相符。实验结果表明,晶体热导率随温度升高呈下降趋势,YAG激光晶体经Yb离子掺杂后热导率值降低,GGG晶体热导率随掺杂Nd离子浓度的增加而降低,并从理论上对实验结果进行了解释。Abstract: For the sake of studying thermal conduction characteristic of different doped YAG and GGG laser crystals,the thermal conductivities of different doped YAG and GGG laser crystal generated from 273K to 393K were measured by making use of instantaneous measuring method,and the temperature field model of the experimental sample was established,the function of thermal conductivity to the temperature was educed.The obtained conductivity/temperature curves almost conformed with the experimental results.The experimental results make clear that the thermal conductivity of the laser crystal decline to the temperature,the thermal conductivity of YAG laser crystal declines after doped with Yb ions,the thermal conductivity of the GGG laser crystal declines with the rising of the doped Nd ions concentration.Finally,the experimental results were theoretically explained.
-
Keywords:
- materials /
- thermal conductivity /
- measurement study /
- laser crystal
-
-
[1] ZHANG Q L,YIN Sh T,WANG A H et al.Research progress of the laser crystal GGG species[J].Chinese Journal of Quantum Electronics,2002,19(6):481～484(in Chinese).
[2] ZHANG Q L,JIANG H H,YIN Sh T.Properties of LD edge-pumped Yb:YAG laser[J].Laser Technology,2005,29(1):82～86(in Chinese).
[3] JIANG H H,JIA X D,YUAN Z J et al.Lasing features of flash lamp pumped Nd3+:GGG Laser[J].Chinese Journal of Quantum Electronics,2003,20(6):648～650(in Chinese).
[4] WANG Zh B,ZHANG Q L,SUN D L et al.Study on defects of Nd:GGG laser crystal[J].Chinese Journal of Quantum Electronics,2005,22(4):574～578(in Chinese).
[5] KRUPKE W F,SHINN M D,MARION J E et al.Spectroscopic,optical,and thermomechanical properties of neodymium-and chromiumdoped gadolinium scandium gallium garnet[J].Journal of the Optical Society of America,1986,B3(1):102～113.
[6] YANG Q Sh,PUB R.Advanced heat transfer[M].Shanghai:Shanghai Jiaotong University Press,1996.6(in Chinese).
[7] JIA L,FANG Zh H,QIAN X H.Advanced heat transfer[M].Beijing:Advanced Education Press,2003.254(in Chinese).
[8] SLACK G A,OLIVER D W.Thermal conductivity of garnets and phonon scattering by rare-earth ions[J].Phys Rev,1971,B4(2):592～609.
[9] CHENAIS S,DRUON F,BALEMBOIS F et al.Diode-pumped Yb:GGG laser:comparison with Yb:YAG[J].Optical Materials,2003,22(2):99～106.
[10] PFISTNER C,WEBER R,WEBER H P et al.Thermal beam distortions in end-pumped Nd:YAG,Nd:GSGG,and Nd:YLF rods[J].IEEE J Q E,1994,30(7):1605～1615.
[11] JIANG B X,ZHAO Zh W.Room temperature absorption and emission spectra of Nd3+:Gd3Ga5O12 crystal[J].Journal of Synthetic Crystal,2004,33(4):581～585.
