Effect of picosecond pulse compression in photonic crystal fibers
-
摘要: 为了研究初始啁啾和初始输入功率对脉冲压缩的影响,运用对称分步傅里叶方法数值模拟了皮秒高斯脉冲在光子晶体光纤中的传输过程.增大初始啁啾和输入功率可以得到更大的压缩因子,同时最佳光纤长度减小,它们之间基本成线性关系.并且在初始啁啾值和初始功率比较小时,在最佳光纤长度处,品质因子和压缩因子不是同时达到最大值.结果表明,若选取适当的光纤长度和初始峰值功率,可以实现啁啾脉冲在光子晶体光纤中的有效压缩.Abstract: A theoretical investigation with the method of splitstep Fourier was presented on the propagation of a picosecond pulse in photonic crystal fibers.The effect of initial chirp and power on pulse compression was simulated and analyzed.It was found that the compression factor and the compression quality factor increased with initial chirp and power,but optimum fiber length decreased.When the values of initial chirp and power were small,the compression factor and the compression quality factor didn't simultaneously achieve the optimum value.If an appropriate optical fiber length and initial peak power was selected,efficient pulse compression could be attained in photonic crystal fibers.
-
-
[1] MOLLENAUER L F,STOLEN R H,GORDON J P.Experimental observation of picosecond pulse narrowing and solitons in optical fibers[J].Phys Rev Lett,1980,45(13):1095～1098.
[2] GOUVECIA-NETO A S,LGOMES A S,TAYLOR J R.5000-fold compression of picosecond pulses using grating pair and soliton effect at 1.32μm[J].Journal of Modern Optics,1988,35(1):7～10.
[3] RUSSELL P St J.Photonic crystal fibers[J].Science,2003,299(5605):358～362.
[4] KNIGHT J C,BIRKS T A,RUSSELL P St J et al.All-silica single-mode optical fiber with photonic crystal cladding[J].Opt Lett,1996,21(19):1547～1549.
[5] BIRKS T A,KNIGHT J C,RUSSELL P St J.Endlessly single-mode photonic crystal fiber[J].Opt Lett,1997,22(13):961～963.
[6] CHANG G Q,NORRIS T B,WINFUL H G.Optimization of supercontinuum generation in photonic crystal fibers for pulse compression[J].Opt Lett,2003,28(7):546～548.
[7] LIMPERT J,SCHREIBER T,NOLTE S et al.All fiber chirped-pulse amplification system based on compression in air-guiding photonic bandgap fiber[J].Optics Express,2003,11(24):3332～3337.
[8] de MATOS C J S,POPOV S V.All-fiber format compression of frequency chirped pulses in air-guiding photonic crystal fibers[J].Phys Rev Lett,2004,93(10):103901.
[9] DRUON F,GEORGES P.Pulse-compression down to 20fs using a photonic crystal fiber seeded by a diode-pumped Yb:SYS laser at 1070nm[J].Optics Express,2004,12(15):3383～3396.
[10] AGRAWAL G P.Nonlinear fiber optics applications of nonlinear fiber optics[M].Beijing:Publishing House of Electronics Industry,2002.33～40,445(in Chinese).
[11] YANG G Q,YANG X Y.Effect of initial chirp on soliton-effect picosecond pulse compression in optical fibers[J].Laser Infrared,2001,31(4):250～252(in Chinese).
[12] WANG R X.Effect of loss and chirp on picosecond pulse solitoneffect compression[J].Laser Technology,2003,27(5):415～418(in Chinese).
