G-APD arrays——a three dimensional imaging detector with single photon sensitivity
-
摘要: 介绍了一种利用盖革模式雪崩二极管(G-APD)作为成像单元的新型阵列光电探测器,重点介绍了该新型成像光电探测器的关键技术、器件研发和系统应用的发展状况。G-APD阵列探测器兼具单光子探测灵敏度和皮秒级时间分辨率两大特点,适用于对极微弱光目标的三维成像探测。同时,G-APD阵列探测器又是一种全固态的光电探测器件,不仅体积小、重量轻、可靠性高,而且还可用现有的微光电子工艺进行规模化生产。因此,G-APD阵列是目前阵列光电探测器件的一个重大发展,必将在各种高端光电成像领域获得广泛的应用。Abstract: A novel photonics detector arrays consisted of Geiger-mode avalanche photodiodes(G-APD) was introduced.The key techniques,device developments and system integration of this new image detector were emphasized.A G-APD array detector has two outstanding characters:single photon sensitivity and pico-second resolving power,which makes the detector very suitable for the weak optical signal 3-D imaging.On the other hand,the G-APD array detector is all-solid state photonics detection device.It has small size,light weight and high reliability,and it can be mass manufactured with nowadays matured micro photonics device process.Therefore,G-APD array is a great advantage at the array photonics detector development,and it will be applied widely in the advanced photonics imaging area.
-
-
[1] O'KEEFFE J,JACKSON C.Low-light imaging:silicon photon-counting detectors enable next-generation imaging[J].Laser Focus World,2006,42(1):32～35.
[2] OTTE A N,DOLGOSHEIN B,MOSER H G et al.Status of siliconphotomultiplier developments as optical sensors for MAGIC/EUSO-like detectors[A].29th International Cosmic Ray Conference[C].Pune:ICRC,2005.101～106.
[3] SHAH K S,FARRELL R,GRAZIOSO R et al.Position-sensitive avalanche photodiodes for gamma-ray imaging[J].IEEE Transactions on Nuclear Science,2002,49(4):1687～1692.
[4] AGRONSKAIA A V,TERTOOLEN L,GERRITSEN H C.Fast fluorescence lifetime imaging of calcium in living cells[J].Journal of Biomedical Optics,2004,9(6):1230～1237.
[5] HEINRICHS R,AULL B,MARINO R et al.Three-dimensional laser radar with APD arrays[J].Proc SPIE,2001,4377:106～117.
[6] VASILE S,GOTHOSKAR P,FARRELL R et al.Photon detection with high gain avalanche photodiode arrays[J].IEEE Transactions on Nuclear Science,1998,45(3):120～123.
[7] AULL B F,LOOMIS A H,GREGORY J A et al.Geiger-mode ava-lanche photodiode arrays integrated with CMOS timing circuits[A].56th Annual Device Research Conference Digest[C].Charlottesville:ADR,1998.58～59.
[8] ROCHAS A,GöSCH M,SEROV A et al.First fully integrated 2-D array of single-photon detectors in standard CMOS technology[J].IEEE Photonics Technology Letters,2003,15(7):963～965.
[9] FAN Zh G.Photonics detection technology[M].2nd ed,Beijing:Publishing House of Electronics Industry,1987.98～220(in Chinese).
[10] KINDT W J,SHAHRJERDY N H,ZEJJL H W.A silicon avalanche photodiode for single optical photon counting in Geiger mode[J].Sensors and Actuators,1997,A60(1):98～102.
[11] AULL B F,LOOMIS A H,YOUNG D J et al.Geiger-mode avalanche photodiodes for three-dimensional imaging[J].Lincoln Laboratory Journal,2002,13(2):335～350.
[12] NICLASS C,ROCHAS A,BESSE P A et al.A CMOS single photon avalanche diode array for 3-D imaging[A].IEEE International Solid-State Circuit Conference(ISSCC)[C].Switzerland:IEEE,2004.120～121.
[13] ZAPPA F,GULINATTI A,MACCAGNANI P et al.Single-photon avalanche diode arrays[J].IEEE Photonics Technology Letters,2005,17(3):657～659.
[14] NICLASS C,ROCHAS A,BESSE P A et al.Design and characterization of a CMOS 3-D image sensor based on single photon avalanche diodes[J].IEEE Journal Solid-State Circuits,2005,40(9):1847～1854.
[15] NICLASS C,SERGIO M,CHARBON E.A single photon avalanche diode array fabricated in deep-submicron CMOS technology[A].Design,Automation,and Test in Europe,Proceedings of the Conference on Design,Automation and test in Europe[C].Munich:IEEE,2006.81～86.
[16] ALBOTA M A,AULL B F,FOUCHE D G et al.Three-dimensional imaging laser radars with Geiger-mode avalanche photodiode arrays[J].Lincoln Laboratory Journal,2002,13(2):351～370.
[17] ZAYHOWSKI J J,DILL C Ⅲ.Diode-pumped passively Q-switched picosecond microchip laser[J].Opt Lett,1994,19(3):1427～1429.
[18] HEINRICHS R,AULL B F,KOCHER D G et al.Development of 3-D imaging laser radar technology for advanced seekers[A].IRIS Proceedings of Active Systems[C].Denver:IRIS,1997.35～38.
[19] MARINO R M,STEPHENS T,HATCH R E et al.A compact 3-D imaging laser radar system using Geiger-mode APD arrays:system and measurements[A].Laser Radar Technology and Applications Ⅷ,Proceedings of SPIE 5086[C].Orlando:SPIE,2003.1～15.
-
