空气间隙长度对光纤光栅外腔LD激射波长的影响
Influence of air gap on the lasing wavelength of the fiber grating external cavity semiconductor laser
-
摘要: 为了提高光纤光栅外腔半导体激光器的激射波长准确性,根据光纤光栅外腔半导体激光器的相位条件确定光纤光栅外腔半导体激光器的激光纵模分布后,采用数值模拟的方法研究了光纤光栅外腔半导体激光器的激射波长随光纤端头到有源区之间空气间隙长度的变化。结果表明,光纤光栅外腔半导体激光器的激射波长随着空气间隙长度的变化围绕着光纤光栅的布喇格波长波动,波动的最大幅度随外腔长度的增加而减小。因而当外腔长度一定时,可以通过微小的调节空气间隙的长度使激射波长精确定位于光纤光栅的布喇格波长处。Abstract: In order to control accurately the lasing wavelength of the fiber grating external cavity semiconductor laser(FGECSL),after determining the mode distribution based on the phase condition,the influence of the air gap between the head of fiber and the front face of F-P LD on the lasing wavelength of FGECSL was through numerical simulation.The results show that the variation of the air gap will result in the lasing wavelength rippling around the Bragg wavelength of fiber grating(FG),and the amplitude of fluctuation becomes smaller with the increase of the external cavity length.For a fixed length of external cavity,the lasing wavelength can be accurately located in the Bragg wavelength of FG through adjusting the air gap carefully.
-
Key words:
- laser physics /
- external cavity semiconductor laser /
- fiber grating /
- lasing wavelength
-
[1] TIMOFEEV F N,BAYVEL P,MIKHAILOV V,et al.2.5 Gbit/s directly-modulated fibre grating laser for WDM networks[J].Electron Lett,1997,33(16):1406-1407. [2] DOGRU N,OZYAZICI M S,SAYIN M.Small signal intensity modulation of external cavity lasers with fiber Bragg gratings[J].Opt & Quant Electron,2005,37:391-405. [3] SATO T,YAMAMOTO F,TSUJI K,et al.An uncooled external cavity diode laser for coarse-WDM access network systems[J].IEEE Photonics Technology Letters,2002,14(7):1001-1003. [4] LAY T S,YANG H M,LEE C W,et al.Fiber grating laser:a performance study on coupling efficiency of fiber microlens and the Bragg reflectivity[J].Opt Commun,2004,233:89-96. [5] LAY T S,CHEN M H,YANG H M,et al.1.55μm non-anti-reflection-coated fiber grating laser for single-longitudinal mode operation[J].Opt & Quant Electron,2002,34:687-696. [6] XIA G Q,WU Zh M,ZHOU H Q.Influence of external cavity length on lasing wavelength variation of fiber grating semiconductor laser with ambient temperature[J].Optik,2003,114(6):247-250. [7] WU Zh M,XIA G Q.Oscillation wavelength of fiber Bragg gratingsemiconductor lasers[J].Optik,2002,113(8):348-350. [8] KANJAMALA A P,LEVI A F J.A multistate external cavity laser diode[J].A P L,1998,72(18):2214-2216. [9] ZHOU H Q,XIA G Q,FAN Y X,et al.Output characteristics of weak-coupling fiber grating external cavity semiconductor laser[J].Opto-Electronics Review,2005,13(1):27-30. [10] WANG L L,REN J H,ZHAO T G,et al.Theoretical and experimental study on a fiber grating external-cavity semiconductor laser[J].Laser Technology,2005,29(4):361-363(in Chinese). [11] DENG T,XIA G Q,WU Zh M.Influence of the optical feedback on the large signal modulation characteristics of the external cavity semiconductor laser[J].Journal of Materials Science:Materials in Electron,2006,17(4):301-305. [12] XU Q Y,CHEN Sh W.Improved model analysis of fiber bragg grating external cavity semiconductor lasers[J].Chinese Journal of Lasers,2005,32(2):156-160(in Chinese). -
