菱体型相位延迟器对入射角灵敏性的研究

详细信息

Sensitivity of rhomb-type phase retarders to the input angle

1.
Department of Physics, Southwest Guizhou Teachers' College of Nationalities, Xingyi 562400, China;
2.
Institute of Laser Research, Qufu Normal University, Qufu 273165, China;
3.
School of Physics and Electronic Information, China West Normal University, Nanchong 637002, China

摘要: 为了清楚地了解菱体型消色差λ/4相位延迟器对入射角i变化的灵敏性随折射率n变化的规律,利用全反射相变公式详细推导出器件对入射角i变化的灵敏性与折射率n的关系式,并做出了理论曲线。可见,随着折射率n的增加,器件对入射角i的变化更加灵敏。结果表明,设计器件时应尽量避免选择高折射率材料。在分析相位延迟量的测量误差时,这个应用也是很有价值的。
- 光学器件 /
- 消色差 /
- 全反射 /
- 折射率
Abstract: In order clearly to learn the regularity that sensitivity to variations in the input angle of incidence i of a rhomb-type achromatic quarter-wave phase retarder vary with refractive index n,the total reflection phase transformation formula are used to deduce the transmissivity formula of sensitivity to variations in the input angle of incidence i of retarders and refractive index n and draw the theoretical curves.The result indicates that retarders are more sensitive to variations in the input angle of incidence i with refractive index increasing.So the higher refractive index material should be avoided in designing retarders.This application is advantageous in analyzing error in phase retardance measurement.
- optical device /
- achromatism /
- total reflection /
- refractive index

[1]	LI J Z.Optical handbook[M].Xi'an:Science and Technology Press of Shanxi,1986:576-580 (in Chinese).
[2]	CHUN Y.Construction of an optical rotator using quarter-wave plates and optical retarder[J].Opt Engng,1995,34(10):3031-3035.
[3]	XUE G D,FENG L,JIAN J W,et al.Achromatic wave plates for optical pickup units fabricated by use of imprint lithography[J].Opt Lett,2005,30(19):2614-2616.
[4]	JEAN-BAPTISTE M,GUILHEM G.Terahertz achromatic quarter-wave plate[J].Opt Lett,2006,31(9):265-267.
[5]	MCINTYRE C M,HARRIS S E.Achromatic wave plates for visible spectrum[J].J O S A,1968,58(12):1575-1580.
[6]	NAGIB N N.Theory of oblique-incidence phase retarders[J].Appl Opt,1997,36(7):1547-1552.
[7]	ZHAO P T,LI G H,WU F Q.New design of high precision achromatic phase retarder[J].Acta Optica Sinica,2005,25(7):980-983(in Chinese).
[8]	NAGIB N N.Phase retarders with variable angles of total internal reflection[J].Appl Opt,1994,33(7):1218-1222.
[9]	NAGIB N N.Phase retarders highly insensitive to the input angle[J].Appl Opt,1998,37(7):1231-1235.
[10]	LI G L,SONG L K,HAO D Z,et al.Optimal design of homb-type achromatism retarder[J].Laser Technology,2005,30(5):539-540(in Chinese).
