三元复合式消色差λ/4波片使用范围的再研究

详细信息

Application scope of three-element compound achromatic λ/4 wave-plate

摘要: 为了精确得到三元结构的λ/4消色差复合波片的消色差范围,采用数学解析的方法进行了理论分析,并在中心波长600nm处进行实验,得到偏差在2%以内的光谱范围大约为540nm～680nm.结果表明,其消色差范围只在中心波长的附近,这一结果对实验中棱镜的选用是有帮助的.
- 光学器件 /
- 消色差 /
- 复合波片 /
- 等效快轴 /
- 光谱范围
Abstract: In order to find the achromatic scope of three-element compound λ/4 wave-plate,mathematical analysis was performanced and experiments at the center wavelength of 600nm was executed.In the experiment the spectrum range was between 540nm~680nm when the deviation is less than 2%.It is concluded that the achromatic scope is only near the center wavelength,which is very important for practiceal prism selection.
- optical devices /
- achromatism /
- compound wave-plate /
- fast axie of equivalent /
- spectral range

[1]	DRICOLL W G,VAUGHAN W.Handbook of optics[M].New York:McGraw-Hill Book,1978:10-104.
[2]	YUN M J,LI G H.Three-in-one composite achromatic λ/4 wave-plate[J].Journal of Optoelectronics·Laser,2001,12(6):562-564(in Chinese).
[3]	XUE D,LI G H,ZHENG Ch H,et al.Theoretical analysis of the fast axis' equivalence principle of composite wave-plate[J].Lasers Technology,2004,28(1):111-112(in Chinese).
[4]	LI H,SONG L K,LI G H.Orientation effect on phase retardation of compound binary zero-order wave-plate[J].Acta Optica Sinica,2002,22(12):1438-1441(in Chinese).
[5]	LI J Zh.Handbook of optics[M].Ji'nan:Shandong Science Technology Press,1986:582(in Chinese).
[6]	JORG S,THEODOR S K.Liquid crystal phase retarder with broadspectral range[J].Opt Commun,2000,176:313-317.
[7]	ZHENG Ch H,SONG L K.Optimizational design scheme for three-in-one composite achromatic λ/4 wave-plate[J].Chinese Journal of Lasers,2004,31(6):662-664(in Chinese).
[8]	WANG N,LI G H.A simple way of determining the phase delay angle of wave-plate[J].Journal of Qufu Normal University,2001,27(6):47-49(in Chinese).
[9]	SONG L K,LI G H.Design of the three-element combination archromatic retarder made of mica and quartz[J].Journal of Optoelectronics ·Laser,2000,11(1):51-53(in Chinese).
[10]	YUN M J,LI G H,WANG M.Design of three-in-one composite compensator[J].Chinese Journal of Lasers,2001,A28(9):14-15(in Chinese).
