Study on vector light field of laser diodes
-
摘要: 为了实现在利用衍射光学器件整形半导体激光器时,得到半导体激光器各个电磁分量的分布,且该分布能够在较近的距离上仍然适用的目的,采用基尔霍夫衍射理论和非傍轴条件下的菲涅耳近似理论推导和MATLAB语言编制相应的数值计算程序的方法,得到半导体激光器各电磁分量分布的结果。结果表明,除在特殊方向上,半导体激光为TM波和TE波的混合模,数值程序实现了计算不同距离上半导体激光器各个电磁分量的分布情况的功能。这对设计和分析半导体激光器衍射整形光学器件具有重要意义。Abstract: In order to achieve the intensity in the vector light field applicable not far away from the laser diode when applying diffractive optics to shape the beam of laser diode,Kirchhoff diffractive theory and Fresnel approaching method under nonparaxial condition was adopted to derive out each electromagnetic component's distribution and the MATLAB language was adopted to compute the numerical result.The results show that the diode laser is a mixture of TE mode and TM mode except in some special directions,and the function of computing distribution of each electro-magnetic field is realized.The study should be useful for design and analysis of the diffractive optics for LD laser beam shaping.
-
Keywords:
- lasers /
- laser diode /
- optical distribution /
- nonparaxial condition
-
-
[1] BAO N K,CHEN Zh Y,ZHANG J J.Phase-only diffractive optical element for improving the beam quality of a vertical-cavity surface-emitting laser array[J].Optik,2004,115(1):23-27.
[2] FORESI J S,LEVY J,JACKSON J E.Intensity redistribution and collimation of laser diode arrays using binary optics[J].SPIE,1990,1211:253-257.
[3] ASFOUR J M,TSCHUDI T.Beam-shaping of laser diodes with binary diffraction optics[J].SPIE,1994,2041:312-317.
[4] DU B X.The principle of semiconductor laser[M].Beijing:Weapon Industry Press,2004:79-93(in Chinese).
[5] XUE H,ZHANG Q,LI P.The analysis of far-field light intensity characteristic of laser diode[J].Laser Technology,2004,31(4):661-663(in Chinese).
[6] LI Sh Y,YU Y G,YE H Y,et al.The estimation of the parameters in the model of the self-mixing effect in semiconductor lasers[J].Laser Technology,2005,29(5):519-521(in Chinese).
[7] LI Y.Initial research on near field light beam orthopedics design for semiconductor laser[J].Aero Weaponry,2007(1):51-52(in Chinese).
[8] HE X J,YANG H J,QIU Q.The collimation design of the semiconductor laser array light beams[J].Laser Technology,2004,28(6):658-660(in Chinese).
[9] WU X.Beam properties and beam combining technique for semiconductor lasers[D].Hangzhou:Zhejiang University,2004:41(in Chinese).
[10] YANG G,SONG F J.Advance physical optics[M].Hefei:Chinese Science and Technology Press,1989:75-68(in Chinese).
