164W LD侧抽运准连续Nd：YAG/HGTR-KTP高功率绿光激光器
164W LD side-pumped quasi-continuous-wave Nd：YAG/HGTR-KTP green laser
-
摘要: 为了研究百瓦级高光束质量绿光激光器,采用激光二极管侧面抽运双棒串接、双声光调Q的方法,依据光束传输矩阵,分析比较了V型折叠腔内分别置入单、双激光晶体时,其热透镜效应对谐振腔稳定性、折叠臂内光场分布以及倍频晶体处子午光斑和弧矢光斑大小的影响,倍频晶体选用具有抗灰迹特性的Ⅱ类临界相位匹配KTP晶体。当总抽运功率为1200W、重复频率为27.2kHz时,得到了脉冲宽度为130ns的164W准连续绿光输出,光光转换效率为13.7%,光束质量因子Mx2=10.46,My2=10.59。结果表明,使用双棒串接、双声光调QV型腔结构,可以获得百瓦级高功率、高光束质量532nm绿光输出。Abstract: In order to investigate more than one hundred Watt green laser,two serial rods pumped by laser diodes and two Q-switched V-shaped resonators were used.Based on the transmission matrixes,when single and double rods were placed in the cavity respectively,the stable condition of cavity,the light distribution in the folded arm,along with the sagittal and tangential spot size on the nonlinear crystal influenced by the thermal lens effect were analyzed and compared.A high gray tracking resistivity (HGTR)-KTP crystal with type Ⅱ critical phase-matching was adopted as intracavity frequency doubler.When the pump power of two diode lasers was 1200W and the repetition rate was 27.2kHz,164W green laser with the pulse width of 130ns was obtained.The optical-optical conversion efficiency was 13.7%.The beam quality factor was M32=10.46,M32=10.59.The result shows that one hundred Watt green laser could be obtained in the two-rod and two Q-switched V-shaped resonator configuration.
-
Key words:
- lasers /
- high power laser /
- two serial rods /
- thermal lens effect
-
[1] BAI J T,CHEN G F.Continuous-wave diode-laser-end-punped Nd:YVO4/KTP high power solid-state green laser[J].Opt & Laser Technol,2004,34(4):333-336. [2] LI B Ch.Experimental optimization of the output performance of a all-solid-state pulsed Nd:YAG laser[J].Laser Technology,2007,31(2):144-146 (in Chinese). [3] LIU X S,WANG Z Y,YAN X,et al.A high energy good-beam-quality krypton lamp pumped Nd:YAG solid-state laser with one pump cavity[J].Chinese Physics Letters,2008,25(2):521-523. [4] ZHOU R,YAO J Q,XU D G,et al.Study on resonator of 85W all-solid-state green laser[J].Chinese Journal of Lasers,2004,31(6):641-645 (in Chinese). [5] CHAO L,YUAN X,ZHU Ch H,et al.Phase-matching characteristics of 589nm radiation generated by SFG with double-axis crystals[J].Laser Technology,2005,29(5):459-461 (in Chinese). [6] GENG A C,BO Y,BI Y,et al.One hundred and twenty one W green laser generation from a diode-side-pumped Nd:YAG laser by use of a dual-V-shaped configuration[J].Optics and Lasers in Engineering,2006,44(6):589-596. [7] CHEN Y F,HUANG M,KAO C F,et al.Optimization in scaling fiber-coupled laser-diode end-pumped lasers to higher power:influence of thermal effect[J].IEEE J Q E,1997,33(8):1424-1429. [8] ZHANG H L,ZHU N Y,YANG Q S,et al.LD pumped Nd:YVO4/KTP red light laser[J].Acta Photonica Sinacica,2000,29(5):470-472 (in Chinese). [9] XIE H M,CHEN H W,JIA Sh,et al.Double-end-pumped double Nd:YVO4crystals continuous green laser[J].Laser Technology,2006,30(6):597-600 (in Chinese). [10] GUO L,YAO J Q,YU G J,et al.Study on the thermal effect of KTP crystal for 85W green laser[J].Laser Journal,2003,24(6):20-22 (in Chinese). [11] FLUCK R,HERMANN M R,HACKEL L A.Energetic and thermalperformance of high gain diode-side pumped Nd:YAG rods[J].Appl Phys,2000,B70(4):491-498. [12] XIE W,TAM S,LAM Y,et al.Influence of the thermal effect on the TEM00 mode output power of a laser-diode side-pumped solid-state laser[J].Appl Opt,2000,39(30):5482-5487. [13] GUAN J,CHEN G F,CHENG G F,et al.Design of thermal effectcompensation resonator for a sort of high-power end-pumped Nd:YVO4 laser[J].Acta Photonica Sinaca,2003,32(12):1418-1420 (in Chinese). -
