Experimental study of temperature tunable broadband ptical parametric oscillator
-
摘要: 为了获得宽波段的可调谐相干光源,利用1064nm声光调QNd:YAG激光器为抽运源、掺氧化镁周期极化铌酸锂晶体为工作物质,对温度调谐光参量振荡器进行了实验研究。由实验数据可知,当晶体的温度从40℃升高到200℃时,获得信号光的调谐范围为1.565μm～1.670μm;当抽运源脉宽为70ns、重复频率为10kHz、平均功率为1.61W时,获得波长为1631nm信号光的输出功率为211mW。结果表明,温度调谐光参量振荡器可以作为宽波段的可调谐相干光源。
-
关键词:
- 激光器 /
- 光参量振荡器 /
- 可调谐相干光源 /
- 掺氧化镁周期极化铌酸锂晶体 /
- 温度调谐
Abstract: In order to obtain a broadband tunable coherent sottrce,based on Mg0-doped periodically-poled lithium niobate,an optical parametric oscillator(OPO)was pumped by a 1064nm acousto-optically q-witched Nd: YAG laser,which can be conveniently tuned by means of changing its temperature.When the crystal temperature was adjusted from 40℃ to 200℃,the tunable mid-infrared output wavelength shifted from 1.565μN,m to 1.670μm.When the average pump power was 1.61w with about 70ns pulse duration operating at a repetition rate of 10kHz,the maximum signal output power of the OPO was about 211mW at 1631nm.It was shown from the results that temperature tunable optical parametric oscillator was a candidate of broadband tunable coherent sources. -
-
[1] YAO B Q,WANG Y Zh,LIU Q,et al.Comparison of LiNbO3 with KTP optical parametric oscillator operating in mid-infrared spectrum[J].Journal of Harbin Institute of Technology,2003,35(10):1228-1231(in Chinese).
[2] KALMANI G,ARIE A,BLAU P,et al.Polarization-mixing optical parametric oscillator[J].Opt Lett,2005,30(16):2146-2148.
[3] ZHANG H,YAO J Q,ZHANG B G,et al.Angle-tunded optical parametric oscillators based on PPLN pumped by 1064nm laser[J].Journal of Optoelectronics·Laser,2003,14(12):1250-1253(in Chinese).
[4] LIANG X Y,HOU W,LU J H,et al.Low-threshold and wide tunable PPLN optical parametrical oscillator[J].Chinese Journal of Lasers,2002,29(1):10-12(in Chinese).
[5] ZHANG B G,YAO J Q,DING X,et al.Continuously tunable optical parametric oscillator based on multi-grating periodically poled lithium niobate[J].Chinese Journal of Lasers,2004,31(8):897-902(in Chinese).
[6] MYERS L E,ECKARDT R C,FEJER M M,et al.Multigrating quasi-phase-matched optical parametric oscillator in periodically poled LiNbO3[J].Opt Lett,1996,21(8):591-593.
[7] BRYAN D A,GERSON R,TOMASCHKE H E.Increased optical damage resistance in lithium niobate[J].A P L,1984,44(9):847-849.
[8] ZHANG P,YIN Z,WANG L L,et al.Photorefractive effect in periodically poled lithium niobate and lithium tantalate and in MgO-doped lithium niobate[J].Journal of the Korean Physical Society,1998,32(2):450-452.
[9] MYERS L E,ECKARDT R C,FEJER M M,et al.Quasi-phase-matched optical parametric oscillators in bulk periodically poled LiNbO3[J].J O S A,1995,B12(11):2102-2116.
[10] ZHANG B G,YAO J Q,ZHANG H,et al.Temperature tunable infrared optical parametric oscillator with periodically poled LiNbO3[J].Chinese Physics Letters,2003,20(7):1077-1080.
