Effect of impurity absorption on 1-D photonic crystal dual defect modes
-
摘要: 为了研究在1维光子晶体中掺杂具有吸收的零平均折射率材料而产生的孪生缺陷模特性,采用特征矩阵的方法进行了理论分析。结果表明,随着消光系数的变大,会使孪生缺陷模透射率先变大后变小,当其取某一特定值时,高低频缺陷模会出现最大值,但不能同时出现;具有吸收特性的介质在缺陷层中的位置不同,会改变孪生缺陷模透射率的响应曲线。这一结果对开发光子晶体新的应用有重要意义。Abstract: The property of dual defect modes,induced by one-dimension photonic crystals containing absorbing defect layer with zero average refractivity,was studied based on the eigen matrix.The results show the transmissivity of dual defect modes varied with the extinction coefficient,and the transmissivity at high or low frequency defect mode became maximum as the extinction coefficient reached a certain value.However,the transmissivity at high or low defect frequency mode could not reached maximum value at the same time.In addition,the position of absorbing material might affect the response curve of dual defect modes.The conclusion will play an important impact on the application of photonic crystals.
-
Keywords:
- physical optics /
- photonic crystal /
- eigen matrix /
- dual defect mode /
- extinction coefficient /
- increment
-
-
[1] YABLONVICHE E.Inhibited spontaneous emission in solid-statephysics and electronics[J].Phys Rev Lett,1987,58 (20):2059-2061.
[2] JOHN S.Strong localization of photons in certain disordered dielectric super lattices[J].Phys Rev Lett,1987,58(23):2486-2489.
[3] QI J X,WEN Sh Ch.Research of optical properties of one-dimension photonic crystals constructed by positive-negative refractive materials[J].Laser Technology,2006,30(5):504-506(in Chinese).
[4] JIN Y,HUANG Zh Y,CHEN X F,et al.Study on polarization properties of the photonic crystal defect mode[J].Laser Technology,2007,31(3):277-280(in Chinese).
[5] TANG B Sh,SHEN T G.Study on transmission property of two-dimension doped photonic crystals with triangular lattices[J].Laser Technology,2006,30(5):526-528(in Chinese).
[6] YUAN Z H,LU X D,HUANG J.Theoretical study of reflective phase compensator made of photonic crystal[J].Laser Technology,2006,30(5):476-478(in Chinese).
[7] WANG Y H,TANG L,NI Zh W,et al.The defect mode and bistability in the nonlinear Bragg microcavity composed of one-dimension photonic crystal[J].Laser Technology,2006,30(5):462-464(in Chinese).
[8] XU G W,OUYANG Zh B.A new double-wavelength photonic crystal resonator[J].Acta Photonica Sinica,2007,36(3):429-433(in Chinese).
[9] LI J S,ZHOU L,CHAN C T,et al.Photonic band gap from a stack of positive and negative index materials[J].Phys Rev Lett,2003,90(8):083901-083904.
[10] JIANG H T,CHEN H,LI H Q,et al.Omnidirectional gap and defect mode of one-dimensional photonic crystals containing negative-index materials[J].A P L,2003,83(26):5386-5388.
[11] SHI Zh H,GENG J G,YAN K Zh.Defect mode of one-dimensional photonic crystals containing negative refraction materials[J].Acta Sinica Quantum Optica,2007,13(2):129-133(in Chinese).
[12] LIU Q N.Absorb influence to the photonic bandgap of photonic crystal[J].Laser & Infrared,2007,37(6):543-545(in Chinese).
[13] LIU Q N.Effect of impurity absorption on one-dimensional photonic crystal defect mode[J].Chinese Journal of Lasers,2007,34(6):777-780(in Chinese).
[14] WANG H,LI Y P.An eigen matrix method for obtaining the band structure of photonic crystals[J].Acta Physica Sinica,2001,50 (11):2172-2178(in Chinese).
