连续可调纳秒脉冲LD驱动电源的研制

详细信息

Design of drive circuit for continuously adjustable ns pulse LD

Shanghai Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Shanghai 201800, China

摘要: 为了满足单模尾纤输出脉冲半导体激光器及其后级光放大的要求,研制了一种重频、脉宽及峰值电流均连续可调的纳秒脉冲驱动电源.该电源使用功率场效应管作为开关,通过分析其驱动特性,采用合适的栅极驱动电路,从而缩短了脉冲宽度,增加了带负载能力;同时电源中的保护电路采用自断电等保护措施,能有效保证LD的安全工作.实验结果表明,该驱动电源工作稳定,能满足单模尾纤输出脉冲LD重频、脉宽、峰值可调的要求.
- 激光技术 /
- 驱动电源 /
- 半导体激光器 /
- 保护电路
Abstract: In order to meet the need of single-mode pigtailed pulse LD and its later optical amplification,a ns pulse LD drive circuit with variable pulse,frequency and power was designed by using metal oxide semiconductor field effect transistor(MOSFET) as switch.By analyzing the drive characteristic of MOSFET,a suitable grid drive circuit was used,so the pulse width and the ability to bring loads were improved.A protect circuit was designed to protect the expensive LD from over shot,sharps,arcs etc.It is concluded that the drive circuit works stably and is suitable for driving the LD.
- laser technique /
- drive circuit /
- LD /
- protect circuit

[1]	LOU Q H,ZHOU J,KONG L F,et al.Recent progress of high power pulse double cladding fiber lasers[J].Chinese Journal of Quantum Electronics,2005,22(4):510-515(in Chinese).
[2]	LIU X S,LIN J L,ZHANG H M,et al.The study of nanosecond pulsed diode laser driver[J].Laser Technology,2006,30(4):445-448(in Chinese).
[3]	JEONGWOO H,NGUYEN C.A new ultra-wideband,ultra-short monocycle pulse generator with reduced ringing[J].IEEE Microwave and Wireless Components Letters,2002,12(6):206-208.
[4]	LIN X H,SU G B,LIU J Sh,et al.Research in high-peak and narrow-width pulse dirving circuit of LD[J].Piezoelectris & Acoustooptics,2000,22(6):414-417(in Chinese).
[5]	SUN D G,TANG H F.Study on the PWM driver circuit of LD for laser fuze[J].Laser Technology,2007,31(2):217-219(in Chinese).
[6]	HUA W,ZHOU W D.Modern electric & electronic devices and its applications[M].Beijing:Northern Jiaotong University Press,2002:116-121(in Chinese).
[7]	CHEN Z M.Principle of electric & electronic devices[M].Beijing:China Machine Press,1992:113-122(in Chinese).
[8]	ANDRZEJ O,ZDZISLAW S.Fast overcurrent protection system in the cw laser diode driver[J].Proc of SPIE,2000,4237:123-125.
