Study surface emission mechanism of La2O3-Mo cathode by laser deposition
-
摘要: 为了研究镧钼阴极表面发射机制,采用专为研究阴极设计的与俄歇能谱仪相连的脉冲激光沉积装置制备薄膜阴极.通过测量阴极发射性能和原位分析表面成分(原子数分数),研究了阴极表面元素镧La和氧O变化对阴极发射性能的影响.实验发现随着阴极表面镧膜变薄,阴极发射性能逐渐减弱;阴极发射性能与表面元素La,O 的含量有关,表面层中La/O越高,阴极的发射性能越好.结果表明,传统的单原子层理论无法解释镧钼阴极的发射机制;超额镧在镧钼阴极的发射中起到了关键作用.Abstract: In order to study the surface emission mechanism of La2O3-Mo cathode,film cathodes were studied by using a set of equipment,specially designed for cathode research,with which film cathode can be prepared by pulse laser deposition.In order to gain insight into the relation between cathode emission properties and the cathode surface La/O ratio,electron emission properties and surface compositions(lanthanum and oxygen) of the cathodes were investigated experimentally.Experiment results indicate that the emission current densities descent gradually along with surface lanthanum film thickness attenuation;the cathode emission properties are determined intensively by the surface atomic La/O ratios.The higher the La/O ratio gets,the better the emission property reaches.Then the theory of La2O3-Mo cathode emission mechanism was discussed.It indicates that the theory of monoatomic layer can't explain perfectly emission mechanism of La2O3-Mo cathode;the excess active lanthanum is crucial element to the improvement of thermionic emission.
-
Keywords:
- laser technique /
- thermionic emission /
- emission mechanism /
- pulse laser deposition /
- thin film
-
-
[1] ENGELSEN D.The wisdom of a centenary[C]//Proceedings of the 5th International Vacuum Electron Sources Conference.Beijing:Chinese Institute of Electronics,2004:29-33.
[2] GOEBEL D M,HIROOKAY CAMPBELL G A.Large area lanthanummolybdenum electron emitters[J].Review of Scientific Instrument,1985,56(10):1888-1896.
[3] NIE Z R.Study on thermionic emission of rare earth molybdenum/tungsten cathode materials[D].Changsha:Central South University of Technology,1997:104-107(in Chinese).
[4] WANG J Sh,ZHOU M L,ZUO T Y,et al.Emission mechanism ofLa2O3-Mo cathode[J].Acta Metallurgica Sinica,2001,37(6):668-672(in Chinese).
[5] WANG J Sh,ZHOU M L,WANG Y M,et al.Chemical states of lanthanum in carbonized La2O3-Mo thermionic cathode materials[J].Journal of Rare Earths,2003,21(5):538-543.
[6] XI X L,NIE Z R,HAO Sh M,et al.Surface behavior and emissionproperties of nano-composite W-La2O3 material[J].The Chinese Journal of Nonferrous Metals,2005,15(6):907-911(in Chinese).
[7] HAO Sh M,NIE Z R,YANG J C,et al.La-Mo film cathode preparation and analysis in situ[C]//Proceedings of the 5th International Vacuum Electron Sources Conference.Beijing:Chinese Institute of Electronics,2004:204-205.
[8] AO Y H,HU Sh L,LONG H,et al.Study on pulsed deposition technology[J].Laser Technology,2003,27(5):453-459(in Chinese).
[9] YANG J C,NIE Z R,XI X L,et al.Emission ability of La-Sc-Mo cathode[J].Applied Surface Science,2004,229(1):51-55.
