LD端面抽运Nd：YAP 1341.4nm激光器

基金项目:

国家自然科学基金资助项目(60208001)

详细信息

LD end-pumped 1341.4nm Nd：YAP laser

1.
Fujian Institute of Research on the Structure of Matter, Chinese Academy of Sciences, Fuzhou 350002, China;
2.
School of Physics and Opto-Electronics Technology, Fujian Normal University, Fuzhou 350007, China

摘要: 为了研究Nd:YAP晶体在LD端面抽运中的1341.4nm激光输出特性,采用理论计算和实验测量了实验系统的热焦距,对比了平平腔和平凹腔激光输出结果。采用输出耦合率为T=2.4%的平凹腔和输出耦合率为T=2.6%的平平腔,分别得到了3.15W和2.86W的1341.4nm线偏振激光输出,对应斜效率分别为18.4%和17.5%。结果表明,Nd:YAP作为1.3μm波段激光晶体具有潜在的优点。
- 激光器 /
- 近红外 /
- 端面抽运 /
- Nd：YAP
Abstract: In order to study the output characteristics of diode-end-pumped Nd: YAP laser operating at 1341.4nm,the thermal focal lengths of end-pumped Nd:YAP laser were calculated and measured, and the output results of lasers with plane-plane and plano-concave resonators were compared respectively.Making use of plane-concave resonator with the coupler transmission of 2.4% and plane-plane cavity with the coupler transmission of 2.6%,3.15W and 2.86W linearly polarized laser radiation at 1341.4 nm were obtained,respectively,corresponding optical slope efficiency of 18.4% and 17.5%.The results show that Nd:YAP laser crystal owns the potential advantages on 1.3μm laser.
- lasers /
- near infrared /
- end-pumped /
- Nd：YAP

[1]	WEI Y,ZHANG G,HUANG Ch H,et al.A single wavelength 1318.8nm Nd:YAG laser[J].Laser Technology,2005,29(3):258-260(in Chinese).
[2]	BI Y,SUN Z P,LI R N,et al.High power blue Nd:YAG laser by intracavity summing frequency[J].Optics and Precision Engineering,2005,13(1):16-21(in Chinese).
[3]	JIA F,WANG X Q,MA J Z.Report on 45 patients with digestive diseases who were treated by the Nd:YAP laser with endoscope[J].Chinese Journal of Lasers,2001,28(11):1054-1056(in Chinese).
[4]	HAMISH O,MICHAEL J W,PETER D,et al.Efficient diode double-end-pumped Nd:YVO4 laser operating at 1342nm[J].Optics Express,2003,11(19):2411-2415.
[5]	YE Y C,LIN W X,WANG G F,et al.Study on LD-pumped Nd:KGW thin-disk laser[J].Laser Technology,2006,30(5):536-538(in Chinese).
[6]	SHEN H Y,ZENG R R,ZHOU Y P,et al.Comparison of simultaneous multiple wavelength lasing in various neodymium host crystals at transitions from 4F3/2-4I11/2 and 4F3/2-4I13/2[J].A P L,1990,56(20):1937-1938.
[7]	ZHU H Y,ZHANG G,HUANG C H,et al.High-power CW diode-side-pumped Nd:YAP laser at 1341.4 nm[J].High Power Laser and Particle Beams,2006,18(9):1413-1416(in Chinese).
[8]	SHEN H Y,ZHOU Y P,ZENG R R,et al.Laser action of Nd:YAlO3 at 1300nm[J].J A P,1991,70(6):3373-3374.
[9]	CHEN Y F,TSAI S W.Diode-pumped Q-switched Nd:YVO4 yellow laser with intracavity sum-frequency mixing[J].Opt Lett,2002,27 (6):397-399.
[10]	ZHOU B K,GAO Y Z,CHEN T R,et al.laser principles[M].Beijing:National Defense Industry Press,2000:46-48(in Chinese).
