Wavelength conversion based on cross-phase modulation
-
摘要: 为了研究全光波长转换的实现方法,采用色散位移光纤中脉冲光和连续波间的交叉相位调制效应,使得连续波产生频移和展宽,然后利用光纤光栅滤波,得到了重复频率为57.97MHz、脉冲宽度为2ns的转换脉冲,这与抽运脉冲重复频率、脉冲宽度基本相同,而且连续波可调范围是1537nm~1560nm。结果表明,基于色散位移光纤中交叉相位调制效应的波长转换具有较宽的波长转换范围和较快的转换速度,是一种简单、高效和通用的波长转换技术。Abstract: The cross-phase modulation(XPM) between pulse train and continuum wave in dispersion-shifted fiber(DSF) is utilized to implement all-optical wavelength conversion.The frequency shift and broadening of continuum wave induced by XPM in DSF was experimentally observed.Then wavelength conversion was achieved through filtering by a fiber grating.The converted pulse train with repetition rate of 57.97MHz,pulse-width of 2ns and the modulation period of continuum wave of 1537nm~1560nm,almost as the same of pump pulse,was obtained.The results show that wavelength conversion based on cross-phase modulation of DSF is simple,efficient and universal with wide conversion range and high rate.
-
Keywords:
- fiber optics /
- wavelength conversion /
- cross-phase modulation /
- fiber grating
-
-
[1] ELMIRGHANI J M H,MOUFTAH H T.All-optical wavelength conversion:technologies and application in DWDM network[J].IEEE Communication Magazine,2000,38(3):86-92.
[2] LI M,SUN J Q,LIU D M,et al.Study on degradation of extinction ratio of wavelength converter based on XGM[J].Laser Technology,2001,25(1):76-79(in Chinese).
[3] ZHANG X L,SUN J Q,XU W Ch,et al.Experimental study on2.5Gbit/s all optical wavelength conversion based on cross gain modulation[J].Laser Technology,2001,25(2):115-117(in Chinese).
[4] DONG J J,ZHANG X L,WANG Y,et al.Extinction ratio characteristics of wavelength converters based on single-port-coupled SOA[J].Laser Technology,2001,25(1):14-17(in Chinese).
[5] OLSSON B E,OHLEN P,RAU L,et al.A simple and robust 40Gbit/s wavelength converter using fiber cross-phase modulation and optical filtering[J].IEEE Photonics Technology Letters,2000,12(7):846-848.
[6] OHLEN P,OLSSON B E,BLUMENTHAL D J.Wavelength dependence and power requirements of a wavelength converter based on XPM in a dispersion-shifted optical fiber[J].IEEE Photonics Technology Letters,2000,12(5):522-524.
[7] YU J,JEPPESEN P.80Gbit/s wavelength conversion based on cross-phase modulation in high-nonlinearity dispersion-shifted fiber and optical filtering[J].IEEE Photonics Technology Letters,2001,13(8):833-835.
[8] PERLIN V E,WINFUL H G.All-optical wavelength conversion using cross-phase modulation and Bragg gratings[J].IEEE Photonics Technology Letters,2002,14(2):176-178.
[9] YU J,ZHENG X,PEUCHERET C,et al.All-optical wavelength conversion of short pulses and NRZ signals based on a nonlinear optical loop mirror[J].IEEE Journal of Lightwave Technology,2000,18(7):1007-1017.
