周期性极化掺镁铌酸锂晶体光参量振荡研究

曾江斌; 陈怀熹; 梁万国; 缪龙; 周煌; 冯新凯; 邹小林; 李广伟

doi:10.7510/jgjs.issn.1001-3806.2016.03.023

周期性极化掺镁铌酸锂晶体光参量振荡研究

1.
福州大学材料科学与工程学院, 福州 350116;
2.
中国科学院福建物质结构研究所, 福州 350002

作者简介: 曾江斌(1988-),男,硕士研究生,主要从事非线性光学的研究。.

通讯作者: 梁万国, wgl@fjirsm.ac.cn ;

基金项目:
中国科学院科研装备研制资助项目
中图分类号: O437.4

Research of optical parametric oscillation of periodically poled MgO-doped LiNbO3 crystal

1.
College of Materials Science and Engineering, Fuzhou University, Fuzhou 350116, China;
2.
Fujian Institute of Research on the Structure of Matter, Chinese Academy of Sciences, Fuzhou 350002, China

Corresponding author: LIANG Wanguo, wgl@fjirsm.ac.cn ;

CLC number: O437.4

摘要: 为了实现高转化率3m红外激光光参量振荡输出,采用外加脉冲电场法在厚度为1mm、掺摩尔分数为0.05的镁铌酸锂晶体上成功制备了周期为31.2m的极化光栅,理论计算并模拟了1064nm激光抽运周期极化铌酸锂晶体时,闲频光波长随温度的对应关系,并进行了实验验证。利用1064nm声光调Q Nd:YAG激光器作为抽运源对样品进行了光学参量振荡实验,其中,脉冲激光脉宽为200ns,重复频率是20kHz。在控制温度为80℃、输入抽运光功率为5.567W时,光参量振荡输出波长3m的闲频光功率为1.141W,光光转换效率达到20.1%。结果表明,通过此方法制备的周期性极化铌酸锂晶体光参量振荡,具有较高的光光转换效率。
- 非线性光学 /
- 光参量振荡 /
- 周期性极化掺镁铌酸锂晶体 /
- 准相位匹配
Abstract: In order to achieve high conversion rate of 3m infrared laser output from an optical parametric oscillation, by using the applied pulse electric field method, periodically poled grating of 31.2m was prepared on MgO-doped(mole fraction of 0.05) lithium niobate crystal with the thickness of 1mm. The relationship between idler wavelength and temperature when periodically poled MgO-doped LiNbO3 pumped by 1064nm pulsed laser was studied by theoretical calculation and simulation. Acousto-optic Q-switched Nd:YAG laser with the wavelength of 1064nm was used as the fundamental source to operate optical parametric oscillation experiment with pulse width of 200ns and repetition rate of 20kHz. When pulse input power is 5.567W at the temperature of 80℃, idler output power of 1.141W was obtained with output wavelength of 3m. The maximum conversion efficiency from incident pump power to idler output was 20.1%. The results show that this method of preparation by periodically poled lithium niobate optical parametric oscillation has high optical conversion efficiency.
- nonlinear optics /
- optical parametric oscillation /
- periodically poled MgO-doped LiNbO3 /
- quasi phase match

[1]	QIN X F, ZHOU W D. Progress of mid-infrared continuous wave optical parameter oscillator technique based on PPLN crystal[J]. Chin-ese Journal of Lasers, 2013, 37(2):198-203(in Chinese).
[2]	LIANG X Y, HOU W, LU J H, et al. All-solid-state pumped tunable PPLN optical parametric oscillator[J]. Acta Optica Sinica, 2001, 21(9):1148-1149(in Chinese).
[3]	CHEN Sh Zh, CHEN B. Appication of Infrared technology in military[J].Optical Technique, 2006, 32(s1):581-586(in Chinese).
[4]	MYERS L E, ECKARDT R C, FEJER M M, et al. Quasi-phase-matched optical parametric oscillators in bulk periodically poled LiNbO3[J].Journal of the Optical Society of America, 1995,B12(11):2102-2116.
[5]	BADER U, BARTSCHKE J, KLIMOV I, et al. Optical parametric oscillator of quasi-phase matched LiNbO3 pumped by acompact high repetition rate single-frequency passively Q-switched Nd:YAG laser[J]. Optics Communications,1998, 147(1/3):95-98.
[6]	BUTTERWORTH S D, PRUNERI V, HANNA D C. Optical parametric oscillation in periodically poled lithium niobate based on continuous-waves pumping at 1.047mm[J]. Optics Letters, 1996, 21(17):1345-13457.
[7]	YAN C X, WANG H J, JIN Sh. Study on infrared spectrum of optical parametric oscillator[J]. Chinese Journal of Lasers, 2011, 38(10):1015003(in Chinese).
[8]	GRILLI R, CIAFFONI L, HANCOCK G, et al. Mid-infrared ethene detection using difference frequency generation in a quasi-phase-mat ched LiNbO3 waveguide[J]. Applied Optics, 2009, 48(30):5696-5703.
[9]	WEI X B. Research on mid-infrared PPLN-OPO[D]. Mianyang:China Academy of Engineering Physics, 2010:1-93(in Chinese).
[10]	XIE Y Zh, WAN Y. Study on mid-infrared laser PPMgLN optical parametric oscillators[J]. Laser Technology, 2014, 38(2):368-371(in Chinese).
[11]	LIN D, ALAM S U, SHEN Y, et al. An all-fiber PM MOPA pumped high-power OPO at 3.82 microns based on large aperture PPMgLN[J]. Proceedings of the SPIE, 2012, 8237:82371k.
[12]	YAO J H, LI G G, XU J J, et al. New development of quasi-phase-matching (QPM) technique[J]. Chinese Journal of Quantum Electronics, 1999, 16(4):290-294 (in Chinese).
[13]	DENG H R, LI T. Theory analysis of 2m laser output based on PPLN[J]. Laser Technology,2013,37(1):63-67 (in Chinese).
[14]	YAMADA M, NADA N, SAITOH M, et al. First-order quasi-phase-matched LiNbO3 waveguide periodically poled by applying an external field for efficient blue second-harmonic generation[J]. Applied Physics Letters, 1993, 62(5):435-436.
[15]	ISHIZUKI H, SHOJI I, TAIRA T. Periodical poling characteristics of congruent MgO:LiNbO3 crystals at elevated temperature[J]. Applied Physics Letters, 2003, 82(23):4062-4064.
[16]	KURODA A, KURIMURA S. Domain inversion in ferroelectric MgO:LiNbO3 by applying electric fileds[J]. Applied Physics Letters, 1996, 69(11):165-167.
[17]	BRYAN D A, GERSON R, TOMASCHKE H E. Increased optic damage resistance in the lithium niobate[J]. Applied Physics Letters, 1984, 44(9):847-849.
[18]	YAO J H, CHEN Y H, DENG H L, et al. Study on periodically polarization characteristics of near stoichiometric MgO-doped LiNbO3 crystal[J]. Journal of Infrared and Millimeter Waves,2003, 22(1):35-39.
