Research of microstructure and properties of tungsten based alloy fabricated by laser solid forming
-
摘要: 为了制备高性能、大尺寸钨合金零件,利用激光立体成形技术进行了前期探究实验,在大气环境下制备多种配比的W-Ni-Fe高比重合金力学拉伸试验件,通过测试抗拉强度、硬度,结合组织结构和成分配比的探究分析,发现其成形性及力学性能与传统的粉末冶金烧结工艺之间还存在着一定的差距。抗拉强度在W原子数分数为0.6时达到最大值717.5MPa,之后随着W原子数分数的增大反而明显减小,当W原子数分数在0.8以上时,强度已低于400MPa。样品存在孔洞和氧化现象,大量W未溶化,Ni和Fe元素越多,微观组织均匀性越好、成分偏析越小。结果表明,利用激光立体成形技术可对钨基合金堆积成形,但是实验工艺参量和实验环境仍需进一步改进。此研究可获得免受大气气氛影响和工艺参量限制的试样,为获得性能更好的高比重钨合金激光立体成形件提供了帮助。
-
关键词:
- 激光技术 /
- 激光立体成形 /
- W-Ni-Fe高比重合金 /
- 性能检测 /
- 组织分析
Abstract: In order to prepare high-performance and large-size tungsten alloy parts, the preliminary experiments were carried out by using the laser solid forming technique. Various proportions of W-Ni-Fe high-density alloy mechanical tensile test pieces were prepared under atmospheric conditions. By testing tensile strength and hardness, by analyzing the structure and the compents proportions, the differences between the traditional powder metallurgy sintering process and formability and mechanical properties were found. The results show that the maximum tensile strength reaches 717.5MPa under 0.6 of W atomicity fraction and it decreases significantly with the increase of W atomicity fraction. When atomicity fraction of W atom is more than 0.8, the strength is lower than 400MPa. Holes and oxidation phenomenon exist in the samples. A large number of W doesn't melt. The more Ni, Fe elements, the better microstructure uniformity, the smaller composition segregation. The results preesent that tungsten alloy can be formed by laser solid forming technique but experiment process parameters and experimental environment remain to be further improved. Samples can be obtained free from effect of atmosphere and process parameters limits based on this study. Furthemore, the study is helpful to obtain better performance of tungsten alloy laser solid forming parts. -
-
[1] FAN A G, SHI Y H. Research progress of high performance bombed tungsten heavy alloy in foreign[J]. Ordnance Material Science and Engineering, 1999, 22(1):45-48(in Chinese).
[2] ZHONG M L, LIU W J, NING G Q, et al. Laser direct manufacturing of tungsten nickel collimation component[J]. Journal of Materials Processing Technology, 2004, 147(2):167-173.
[3] GU D D, SHEN Y F, PAN Y F, et al. Study on direct metal laser sintering forming mechanism[J]. Journal of Materials Engineering, 2004, 5(1):42-48(in Chinese).
[4] ZHONG M L, YANG L, LIU W J, et al. Laser direct manufacturing of alloy W/Ni space telescope collimator[J]. Chinese Journal of Lasers, 2004, 31(4):482-486(in Chinese).
[5] MING X L, CHEN J, TAN H, et al. Coarsening behavior of gamma phase in GH4169 superalloy fabricated by laser solid forming[J]. Journal of Materials Engineering, 2014, 15(8):8-14(in Chinese).
[6] LIU F Ch, LIN X, YU X B, et al. Evolution of interface and crystal orientation of laser solid formed GH4169 superalloy during recrystallization[J]. Acta Metallurgica Sinica, 2014, 50(4):463-470(in Chinese).
[7] QIAN Y H, TAN H, LI J, et al. Microstructure characterization of laser solid forming Ti-6Al-4V alloy by high power[J]. Rare Metal Materials and Engineering, 2014, 43(9):2162-2166(in Chinese).
[8] YANG J Q, CHEN J, ZHAO W Q, et al. Study on the rate of crack propagation of laser solid forming of TC11DT titanium alloy[J]. Applied Laser, 2014,34(4):277-282(in Chinese).
[9] LI J, LIN X, QIAN Y H, et al. Study on microstructures and mechanical properties of TC4 titanium alloy by laser solid forming[J]. Chinese Journal of Lasers, 2014,41(11):29-33(in Chinese).
[10] CHEN J, ZHANG R, ZHANG Q, et al. Influence of laser solid forming Ti60 alloy microstructure and defects on the performance[J]. Rare Metal Materials and Engineering, 2014, 43(3):548-552(in Chinese).
[11] ZHANG X H, LIN X, CHEN J, et al. Effect of heat treatment on Microstructure and mechanical properties of TA15 alloy by laser solid forming[J]. Rare Metal Materials and Engineering,2011,40(1):142-147(in Chinese).
[12] ZHAO W Q, CHEN J, YANG J Q, et al. Influence of laser solid forming process on microstructure and mechanical properties of TC11 titanium alloy[J]. Applied Laser, 2012,32(6):479-483(in Chinese).
[13] ZHANG Q, CHEN J, HAN Ch X, et al. Laser repair heat affected zone depth on tensile properties of TC17-TC11 dual alloy[J]. Applied Laser, 2012,32(4):267-271(in Chinese).
[14] YANG H O, SONG M H, YANG D H, et al. The evolution of laser solid forming of 300M ultra high strength steel organization[J]. Applied Laser, 2011,5(4):32-37(in Chinese).
[15] WU X Y, LIN X, L X W, et al. Research on the microstructure and properties of 17-4 PH stainless steel by laser solid forming[J]. Chinese Journal of Lasers, 2011,38(2):37-42(in Chinese).
[16] SUN Y Y, HUANG W. Progress of the application of selective laser processing technology in the field of oral medicine[J]. Journal of Dental Prevention and Treatment, 2014,22(2):109-112(in Chinese).
[17] WANG Y, LI Y. Application and analysis of biological toxicity of Ti Zr alloy in oral repair[J]. Guide of China Medicine, 2012,10(12):234-235(in Chinese).
[18] YAN X D. Study on preparation and properties of Ti Zr alloy laser solid forming powder for dental restoration[D]. Xi'an:The Fourth Military Medical University, 2005:6-8(in Chinese).
[19] LI J M, WANG Ch M,YAN F, et al. Study on microstructure and mechanical properties of 6005A joint in laser-MIG hybrid welding[J]. Laser Technology,2014,38(6):733-737(in Chinese).
[20] ZHANG M K, SUN G F, ZHANG W, et al. Study on corrosion property of laser surface alloyed Cr-CrB2 layers on stainless steel[J]. Laser Technology,2014,38(2):240-245(in Chinese).
[21] HUANG W D. Laser solid forming[M]. Xi'an:Northwestern Polytechnical University Press,2007:16(in Chinese).
-
