1维石墨烯光子晶体的电磁吸收特性

宁仁霞; 刘少斌; 章海锋; 孔祥鲲; 卞博锐

doi:10.7510/jgjs.issn.1001-3806.2015.01.006

1维石墨烯光子晶体的电磁吸收特性

1.
黄山学院机电与信息工程学院, 黄山 245041;
2.
南京航空航天大学电子信息工程学院雷达成像与微波光子技术教育部重点实验室, 南京 210016

作者简介: 宁仁霞(1978-),女,讲师,主要从事等离子体光子晶体、石墨烯光子晶体电磁特性研究。E-mail:nrxxiner@hsu.edu.cn.

基金项目:
国家自然科学基金资助项目(61307052);航空科学基金资助项目(20121852030);江苏省自然科学基金资助项目(BK2011727);黄山学院科研资助项目(2010xkj006);江苏省普通高校研究生科研创新计划资助项目(CXZZ13-0166);安徽省教育厅自然科学研究资助项目(KJ2013B267);大学生创新创业训练计划资助项目(201210375030)
中图分类号:
O734

Electromagnetic absorption characteristics of 1-D graphene photonic crystals

1.
College of Mechanical and Information Engineering, Huangshan University, Huangshan 245041, China;
2.
Key Laboratory of Radar Imaging and Microwave Photonics of Ministry of Education, College of Electronic and Information Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
CLC number:
O734

摘要: 为了研究1维石墨烯光子晶体在可见光波段的吸收特性,采用传输矩阵的方法进行了理论分析和数值仿真,得到了1维石墨烯吸收特性与石墨烯层数、缺陷层介质厚度、电磁波模式有关的结果。结果表明,增加石墨烯层数时,对波长为556nm左右的绿光的吸收作用明显增强;缺陷层介质厚度增加时会引起吸收峰的增加;在TE模式下,入射角对石墨烯光子晶体吸收特性影响较小。该研究结果为1维石墨烯光子晶体吸收器的设计提供了理论依据。
- 光电子学 /
- 吸收特性 /
- 传输矩阵法 /
- 石墨烯光子晶体
Abstract: In order to study the absorption characterisctics of 1-D graphene photonic crystal in the visible band, theoretical analysis and numerical simulation were conducted by using transfer matrix method. The dependance of absorption characterisctics of 1-D graphene on graphene layers, dielectric thickness of defect layers, and electromagnetic mode were obtained. The results show that the absorption with green light of wavelength of about 556nm is enhanced significantly with the increasing of the layers of graphene. The absorption peak will increase with the increasing of dielectric thickness of defect layer. In the TE mode, the angle of incidence has a little effect on the absorption characterisctics of graphene photonic crystal. The results provide the theoretical basis for the study of 1-D graphene photonic crystal absorbers.
- optoelectronics /
- absorption characterisctics /
- transfer matrix method /
- graphene photonic crystal
