光阑约束和离轴失调Lohmann系统的分数傅里叶变换

基金项目:

国家自然科学基金资助项目(10604045)

详细信息

Fractional Fourier transform of hard-edge apertured and misaligned Lohmann’s optical system

摘要: 为了研究受硬边光阑约束及失调Lohmann光学系统对分数傅里叶变换的影响,采用了平顶多高斯光束模型模拟硬边光阑,推导了平面光波在受硬边光阑约束和系统透镜离轴时的Lohmann 型分数傅里叶变换光学系统中传播的解析表达式;计算机模拟了受半径为7.696cm的硬边光阑约束和透镜离轴失调量时的输出.结果表明,在有硬边光阑约束和离轴失调时Lohmann两种结构并不等效.
- 傅里叶光学与光信号处理 /
- Lohmann光学系统 /
- 硬边光阑 /
- 失调
Abstract: To study the influence of hard-edge apertured and misaligned Lohmann's optical system on fractional Fourier transforms,the flat-topped multi-Gaussian beam model was adopted to simulate hard-edge apertures.The analytical expressions for transformation of plane wave in a hard-edge apertured and off-axis Lohmann's fractional Fourier transform optical system were derived.The numerical simulation for outputs when the system was apertured with aperture radius of 7.696cm and the lenses were off-axis was also given.It is shown that the two Lohmann's setups are not equivalent when they are apertured and misaligned.
- Fourier optics and optical signal processing /
- Lohmann’s optical system /
- hard-edge aperture /
- misalignment

[1]	MENDLOVIC D,OZAKTAS H M.Fractional Fourier transforms and their optical implementation Ⅰ[J].J O S A,1993,A10(9):1875-1881.
[2]	OZAKTAS H M,MENDLOVIC D.Fractional Fourier transforms and their optical implementation Ⅱ[J].J O S A,1993,A10(12):2522-2531.
[3]	OZAKTAS H M,MENDLOVIC D.Fourier transforms of fractional order and their optical interpretation[J].Opt Commum,1993,101:163-169.
[4]	LOHMANN A W.Image rotation,wigner rotation,and fractional Fourier transform[J].J O S A,1993,A10(10):2181-2186.
[5]	ZHAO G P,LÜB D.Propagation of Gaussian beams passing through complicated ABCD optical system with internal hard-edge aperture[J].Laser Technology,2003,27(4):299-301(in Chinese).
[6]	LIU Y X,JI X L,LÜB D.Comparative study of simulation algorithm for hard-edge optics[J].Laser Technology,2004,28(6):652-654(in Chinese).
[7]	LIU H Zh,XU R W,LIU L R,et al.Far-field approximation and divergence of Gaussian beam with phase aberrations diffracted by a circular aperture[J].Acta Optica Sinica,2005,26(1):131-135(in Chinese).
[8]	SUN D,ZHAO D W.Wigner distribution function of Hermite-cosine-Gaussian beams through an apertured optical system[J].J O S A,2005,A22(8):1683-1690.
[9]	MAO H D,ZHAO D W.Different models for a hard-aperture function and corresponding approximate analytical propagation equations of a Gaussian beam through an apertured optical system[J].J O S A,2005,A22(4):647-653.
[10]	TOVAR A A.Propagation of flat-topped multi-Gaussian laser beams[J].J O S A,2001,A18(8):1897-1904.
