Implementation of wavelet denoising algorithm based on FPGA
-
摘要: 为了解决传统频域去噪法在光信号处理中单分辨率的局限性,提出了具有多分辨性的小波去噪法,并通过对比验证其有效性。由于小波去噪实现对硬件的要求较高,采用现场可编程门阵列做硬件平台来实现基于分布式算法的小波运算,将复杂的乘法运算转化为简单的并行查表累加过程,提高了运算效率,完成了小波算法的硬件移植。最后设计了基于现场可编程门阵列的采集系统,并在其上进行了小波去噪的硬件验证。结果表明,小波去噪算法在现场可编程门阵列平台上得到了很好的实现,且去噪效果良好。Abstract: In order to solve the limitation of single resolution in optical signal processing with traditional frequency domain denoising method, a multi-resolution wavelet denoising method was put forward. The effectiveness of wavelet denoising method was verified through contrast. According to the high requirements of hardware platform in wavelet denoising method, a field-programmable gate array (FPGA) was put forward as hardware platform. The wavelet denoising method based on distributed algorithm transforms complicated multiplication to simple parallel look-up table accumulation process. It improved the computational efficiency and completed the hardware transplantation. A storage testing system based on FPGA was designed and the hardware verification was realized. Experimental results showed that the denoising effect was well realized on FPGA.
-
Keywords:
- optical signal processing /
- wavelet denoising /
- distributed algorithm /
- look-up table method /
- FPGA
-
-
[1] CHEN Y D,TANG L,SHENG J X, et al.Fast signal reconstruction from modulus maxima of signal's wavelet transform[J]. Acta Electronica Sinica,1998,26(9):82-85(in Chinese).
[2] XU Y S, WEAVER J B, HEALY D M, et al. Wavelet transform domain filters: a spatially selective noise filtration technique[J]. IEEE Transaction on Image Processing,1994,3(6):747-758.
[3] DONOHO D L,JOHNSTONE I M. Ideal spatial adaptation by wavelet shrinkage[J].Biometrika,1994,81(3):425-455.
[4] DU H,CONG S. The study on wavelet de-noising under the environment of MATLAB[J].Computer Simulation,2003(7):119-123(in Chinese).
[5] ZHANG X, ZHAG D H,LI X X, et al.Image denoising based on wavelet transform[J].Chinese Journal of Scientific Instrument,2006,27(6): 2284-2286(in Chinese).
[6] MA L L,SUN Y Q,YAO A Q.Implementation of wavelet thresholding denoising algorithm based on digital signal processors[J].Shanxi Electronic Technology,2011(1):47-48(in Chinese).
[7] ZHOU W R,DI H W,REN G J.Optimized image denoising algorithm based on wavelet transform[J].Computer Engineering and Design,2005,24(12):3244-3246(in Chinese).
[8] XIONG J.Image denoising based on wavelet transform[J].Computer Science,2007,34(7) :232-234(in Chinese).
[9] LIN Y.Research on signal de-noising methods for movement of weapon automatic mechanisms[D].Taiyuan:North University of China,2009:12-13(in Chinese).
[10] FEI P Y,GUO B L.A high-powered image denoising method based on wavelet transform[J]. Signal Processing,2005,21(6):656-658(in Chinese).
[11] WEI L,YANG R J,CUI X T.Design of FIR filter based on distributed arithmetic and its FPGA implementation[J].Chinese Journal of Scientific Instrument,2008,29(10):2010-2014(in Chinese).
[12] KONG W G,ZHANG G J,ZHANG X J.Design of 1-D DCT IP core structure based on distributed arithmetic[J].Microelectronics & Computer,2008,25(8):143-147(in Chinese).
