Analysis of characteristics of a lateral shear interferometer for on-machine surface measurement
-
摘要: 为探讨和证明双折射晶体激光剪切干涉仪用于在线表面精密测量的可能性,推导了该干涉仪中光传输和实现表面测量的模型,分析了其抗振特性,模拟了相当的振动条件对其抗振特性进行实验测试.分析和实验证明了该干涉仪具有良好的抗振能力,适合应用于在线表面精密测量.Abstract: In order to investigate the possibility of a lateral shear interferometer,which is based on a birefringence crystal shear generator,to be applied to on-machine surface measurement,optical models of the interferometer for light propagation and surface measurement are derived.Its anti-vibration characteristics are analyzed,and a vibration table to simulate different vibration conditions is set up,on which many experiments for surface measurement under different vibration conditions are conducted.The analysis and experimental testing verify the advanced anti-vibration characteristics of the interferometer for on-machine surface measurement.
-
-
[1] HARIHARAN P.Interferometric testing of optical surfaces:Absolute measurements of flatness[J].Opt Engng,1997,36(9):2478～2481.
[2] MALACARA D.Optical shop testing[M].2nd ed,New York:John Wiley Sons Inc,1992.123～172.
[3] EUGENIO G,FRINS M.Phase-shifting shearing interferometry with a variable polarization grating recorded on Bacteriorhodopsin[J].Opt Commun,2004,241:309～314.
[4] LEIBBRANDT G W R,HARBERS G,KUNST P J.Wave front analy-sis with high accuracy by use of a double-grating lateral shearing interferometer[J].Appl Opt,1996,35(31):6151～6161.
[5] ANGELIS M,NICOLA S,FERRARO P et al.Test of a conical lens using a two-beam shearing interferometer[J].Opt Lasers in Engng,2003,39(2):155～163.
[6] IWATA K,KIKUTA H.Measurement of dynamic flow field by optical computed tomography with shearing interferometers[J].Optical Review,2000,7(5):415～419.
[7] KIM S W,CHO W J,KIM B C.Lateral shearing interferometer using square prisms for optical testing of aspheric lenses[J].Measurement Science Technology,1998,9(7):1129～1136.
[8] LI P.A two-plate interferometer and its interference pattern[J].Journal of Modern Measurement,2001,9(2):25～30(in Chinese).
[9] HE Y,WANG Q,CHEN J et al.Triangular shearing interferometer automatic test system[J].Laser Technology,2003,27(3):226～228(in Chinese).
[10] LIU X J,CHANG M,ZHOU L.A new style of shear generator[J].Chinese Journal of Optics Precision Engineering,1999,7(3):103～108(in Chinese).
[11] LIU X J,CHANG M,LI Zh.A common-path phase-shifting shearing interferometer[J].Journal of Huazhong University of Seience Technology,1999,27(3):16～18(in Chinese).
[12] GOODMAN J W.Introduction to Fourier optics[M].2nd ed,New York:McGRAW-HILL Companies,1996.96～120.
