激光器虚拟样机与物理样机方案决策研究

基金项目:

武汉市科技计划资助项目(2002300513305)

详细信息

Scheme decision analysis between physical prototype and virtual prototype for laser

1.
School of Mechanical & Electrical Engineering, Nanchang University, Nanchang 330029, China;
2.
School of Mechanical and Electronics Engineering, Wuhan University of Technology, Wuhan 430070, China

摘要: 对于具体激光器产品的设计,技术方案决策是一个复杂的过程,通常只能定性分析与逻辑判断,难以定量计算和分析。为此,采用层次分析法,以高功率横流CO2激光器为例,对其设计方案的决策作出一个精确的定量分析。通过对层次结构模型中措施层、准则层、目标层的分析,得出物理样机和虚拟样机两方案在准则层和目标层的数值对比关系,用数值计算结果为依据进行方案决策。结果表明,采用虚拟样机技术来研发激光器等比较特殊的产品具有物理样机无法比拟的优点。
- 激光器 /
- 虚拟样机 /
- 物理样机 /
- 层次分析法
Abstract: Technology scheme decision is a complex process for a real laser product.Usually,qualitative analysis and logical judgement are used in this process.It's difficult to analyze in quantitive way.With high power crosscurrent CO2 laser as an example,analysis of hiberarchy process(AHP) is used for decision process between physical prototype(PP) and virtual prototype(VP) in a quantitive way.Through analyzing mearusures,criterias and target in hiberarchy,the quantitive comparative relation between PP and VP in criteria layer and target layer are obtained and it is used to make shceme decision.Results show that it's better for laser development with PP than VP.
- laser /
- virtual prototype /
- physical prototype /
- analysis of hierarchy process

[1]	XIONG G L,GUO B,CHENG X B et al.Collaborative simulatin & virtual prototyping[M].Beijing:Tsinghua University Press,2004.34～38(in Chinese).
[1]	ZHANG Sh Q,LI Y,SUN Y.Introduction of modern manufacturing[M].Beijing:Science Press,2003.357～360(in Chinese).
[2]	LIU F,ZHANG X D,YANG D.Manufacturing systems engineering[M].2nd ed,Beijing:National Defense Industry Press,2000.120～140(in Chinese).
[3]	GUO Y J.Comprehensive evaluation theory and method[M].Beijing:Science Press,2002.71～76(in Chinese).
[4]	CHENG Ch,MA Y W.Investigation of CO2 laser resonator with maximum output power[J].Laser Technology,2002,26(5):346～349(in Chinese).
[5]	YU J,CAI G H,YANG Q M et al.A new method stabilize output intense of a laser[J].Laser Technology,2002,26(6):440～443(in Chinese).
[6]	ZHOU M L.Similarity engineering[M].Beijing:China Machine Press,1998.141～143(in Chinese).
[7]	WU B Sh,FANG M,LI R T et al.Study on validity of virtual prototype based on similarity theory[J].China Mechanical Engineering,2002,13(12):1018～1021(in Chinese).
[8]	WANG Y J,LI G Y,XIONG Zh W et al.Study on the calculating method of similarity degree between virtual prototype and physical protype[J].Machinery,2004,31(3):10～12(in Chinese).
