Research of technical parameters of Nd∶YAG laser scribing silicon film solar cell
-
摘要: 结合国内外激光薄膜加工研究结果,从激光与物质相互作用的角度出发,建立激光切割硅薄膜太阳能电池的柱面坐标理论模型。利用Monte Carlo法求得多层薄膜结构的光场分布,进一步用有限元法(fin ite elem entm ethod,FEM)求得柱面坐标下热平衡方程的数值解。得出了能量密度、脉冲形状、重复频率、光斑形状与切割速度以及切割质量之间的关系。Abstract: An optical-thermal model in cylindrical coordinate of pulsed laser scribing multi-layer thin film solar cell module is established.Monte Carlo method is employed to obtain the light fluencies rate of multi-layer material.Finite element method(FEM) is used to solve the heat equation in cylindrical coordinate.And the connection of the laser energy density,repeatition frequency,the shape of pulse and facula,scribing rate and scribing quality is obtained.
-
Keywords:
- laser technique /
- scribing finite element method /
- solar cell
-
-
[1] MATULIONIS I,NAKADE S,COMPAAN A D et al.Wavelength and pulse duration effects in laser scribing of thin films[A].Photovoltaic Specialists Conference,1997,Conference Record of the Twenty-Sixth IEEE[C].Anaheim,CA:IEEE Press,1997.491～494.
[1] COMPAAN A D,MATULIONIS I,MILLER M et al.Optimization of laser scribing for thin-film photovolaics[A].Photovoltaic Specialists Conference,1996,Conference Record of the Twenty-Fifth IEEE[C].Washington DC:IEEE Press,1996.769～772.
[2] QI J,WANG K L,LIANG M Ch et al.Study on laser scribing of silicon wafer with a Q-switched Nd∶ YAG laser[J].Journal of Materials Engineering,1999,44(3):45～48(in Chinese).
[3] BIANCO N,MANCA O.Two-dimensional transient analysis of absorbing thin films in laser treatments[J].American Society or Mechanical Engineers Journal of Heat Transfer,2000,122(2):113～117.
[4] ANGELUCCI N,BIANCO N,MANCA O et al.Thermal transient analysis of thin film multilayers heated by pulsed laser[J].International Journal of Heat and Mass Transfer,1997,40(11):4487～4491.
[5] GRIGOROPOULOS C P,PARK H K,XU X et al.Modeling of pulsed laser irradiation of thin silicon layers[J].International Journal of Heat and Mass Transfer,1993,36(4):919～924.
[6] KIYAMA S,HIRONO Y,HOSOKAWA H et al.Temperature distribution analysis in multi-layer thin film structure by laser beam irradiation[J].Japan Society of Precision Engineering,1990,56(6):1500～1506.
[7] ONG C K,TAN H S,SIN E H et al.Calculation of melting threshold of crystalline and amorphous materials due to pulsed-laser irradiation[J].Material Science & Engineering,1986,79(3):79～85.
