Experimental study of a hot-cell-free CW CO2 laser at 11μm wavelength region hot bands
-
摘要: 报道了一种非流动传统型连续波凹面光栅选支CO2激光器,为了得到11μm附近的一些热带谱线输出,在不加CO2热吸收池的情况下,通过采用较大曲率半径的凹面闪耀光栅(闪耀波长10.6μm、曲率半径10m、刻线150mm-1)和适当地增加腔长(4.5m)来提高谐振腔的选支能力。除了得到常规带0001-[1000,0200]Ⅰ,ⅡR(56)至P(56)100多条谱线之外,还得到11μm附近其它谱线16条,其中包括0111-0310谱带7条、0011-1110谱带1条、同位素C13O2160001-1000谱线5条、C13O2180001-1000谱线3条。所有谱线的输出功率均在1.6W以上。Abstract: The purpose is to describe the design and the construction of a no-flow conventional CW CO2 laser with line selected by concave grating.In order to obtain the lines at 11μm wavelength region,a concave grating(150lines/mm,blazed at 10.6μm) with a 10m radius curvature and a longer cavity(4.5m) is employed to increase the resolution of the cavity without a hot CO2 absorption cell in the cavity.In this laser,besides more than 100 laser lines observed from R(56) to P(56) in the regular 0001-[1000,0200]Ⅰ,Ⅱ band,another 16 lines in 11μm wavelength region including 7 lines in the 0111-0310 band,1 line in the 0011-1110 band,5 lines in the isotope C13O2160001-1000 band and 3 lines in the isotope C13O2180001-1000 band,are also observed.The output power of every line is above 1.6W.
-
Keywords:
- laser /
- CO2 laser /
- continuous wave(CW) /
- hot CO2 absorption cell /
- isotope hot band
-
-
[1] PATLE C K N.Interpretation of CO2 optical maser experiments[J].Phys Rev Lett,1964,12(21):588～590.
[2] PATLE C K N.Continuous-wave laser action on vibrational-rotational transitions of CO2[J].Phys Rev,1964,136(5):A1187～A1193.
[3] YANG F,HUANG W,ZHANG B et al.Temperature field distribution and thermal distortion of thin film coatings irradiated by CO2 laser[J].Laser Technology,2004,28(3):255～258(in Chinese).
[4] LIU J G,CHEN C H,ZHENG T Sh et al.Experimental study of CO2laser induced locally chemical depositions of copper[J].Laser Technology,2003,27 (1):16～18 (in Chinese).
[5] CHEN C H,LIU J G,ZHENG T Sh et al.The research of adbesion of metal layer deposited on epoxyresin board by CO2 laser induced from aqueous solution[J].Laser Technology,2004,28 (1):26～29 (in Chinese).
[6] LIU J H,XU R F.Laser devices and techniques[M].Beijing:Beijing Institute of Technology Press,1995.35 (in Chinese).
[7] REID J,SIEMSEN K.New CO2 laser bands in 9-11 μm wavelength region[J].A P L,1976,29(4):250～251.
[8] REID J,SIEMSEN K.Laser power and gain measurement on the sequence band of CO2[J].J A P,1977,48(7):2712～2717.
[9] WHITFORD B G,SIEMSEN K J,RIED J.Heterodyne frequence measurements of CO2 laser hot-band transitions[J].Opt Commun,1977,22:261～264.
[10] SOLODUKHIN A S.Hot-cell-free sequence-band CO2 laser[J].Journal of Modern Optics,1987,34(4):577～580.
[11] LI Y D,YI H Y,ZHOU Y W.Experimental study of a CW CO2 laser on the sequence bands[J].Chinese Applied Laser,1999,19 (6):359～360(in Chinese).
[12] EVENSON K M,CHOU Ch Ch,BACH B W et al.New CW CO2 laser lines:The 9μm hot band[J].IEEE J Q E,1994,30 (5):1187～1188.
[13] CHOU Ch Ch,EVENSON K M,ZINK K R et al.New CO2 laser lines in 11μ m wavelength region:New hot bands[J].IEEE J Q E,1995,31 (2):343～345.
[14] LIN J Q,WANG X H,HAN T L et al.Isotope 13CO2 laser and its application[J].Journal of Optoelectronics · Laser,1996,7(2):119～124(in Chinese).
[15] SIDDOWAY J C.Calculated and observed laser transitions using C14O216[J].J A P,1968,39(10):4854～4855.
[16] FREED C,ROSS A H M,DONNELL R G O.Determination of laser line frequencies and vibrational-rotational constants of 12C18O2,13C16O2,and 13C18O2 isotopes from measurements of CW beat frequencies with fast HgCdTe photodiodes and microwave frequency counters[J].J Mol Spectrosc,1974,49(3):439～453.
[17] MA Y W,CHEN Y Q.Laser devices[M].Hangzhou:Zhejiang University Press,2002.56(in Chinese).
[18] CAI B R,WANG R F,WEI G H et al.Laser devices[M].Changsha:Hunan Science and Technology Press,1981.92(in Chinese).
