Generation of tunable dual-wavelength low jitter gain-switched optical pulses
-
摘要: 提出了一种产生可调谐双波长低抖动超短光脉冲的新方法。采用外光注入法来降低增益开关F-P激光脉冲的时间抖动,实现了脉冲光谱的双波长可调谐输出。实验中利用两个多量子阱DFB激光器作为外部种子光源,通过温度控制和偏振态调节使外部种子光有效地耦合到增益开关F-P激光器中,输出的光脉冲时间抖动(均方根)从2.57ps降低至1.06ps,双波长的边模抑制比可达25dB。通过改变DFB激光器和F-P激光器的工作温度,可实现波长从1540nm到1560nm的可调谐输出。
-
关键词:
- 激光技术 /
- 增益开关半导体激光器 /
- 双波长 /
- 光注入 /
- 时间抖动
Abstract: A novel scheme for generating dual-wavelength low timing jitter tunable ultra-short pulses is demonstrated.Injecting the external seeding source to the gain-switched F-P laser diode,a reduction of timing jitter and a tunable dual-wavelength spectrum is achieved.Two multiple quantum-well DFB laser diodes are used as the external-injection seeding source.Adjusting the temperature of the laser diodes and the polarization of the seeding source,the injection seeding source is coupled with the F-P laser diode effectively.A reduction of timing jitter(root-mean-square) from 2.57ps to 1.06ps is achieved,and the output side-mode-suppression-ratio is larger than 25dB.Changing the temperature of the laser diodes,a tunable range from 1540nm to 1560nm is achieved.-
Keywords:
- laser technique /
- gain-switched laser diode /
- dual-wavelength /
- optical injection /
- timing jitter
-
-
[1] ZHU Zh,CHEN L Y,LI H et al.Wavelength stabilization scheme for tunable laser diode based on temperature feedback[J].Laser Technology,2005,29 (1):18～20 (in Chinese).
[2] HE Zh J,MA Y W.Tunable laser with high distinguish ablility[J].Laser Technology,2002,26 (5):338～343 (in Chinese).
[3] WANG D N,SHU C.Tunable dual-wavelength picosecond pulse generation using multiple-optical-path self-seeding approach[J].IEEE Photonics Technology Lettors,1997,9 (9):1211～1213.
[4] ANANDARAJAHP,MAGUIREPJ,CLARKE A et al.Self-seedingof a gain-switched integrated dual-laser source for the generation of highly wavelength-tunable picosecond optical pulses[J].IEEE Photonics Technology Letters,2004,16(2):629～631.
[5] LI Sh P,CHAN K T,LIU Y et al.Multiwavelength picosecond pulses generated from a self-seeded Fabry-Perot laser diode with a fiber external cavity using fiber Bragg gratings[J].IEEE Photonics Technology Letters,1998,10(12):1712～1714.
[6] PENG P Ch,TSENG H Y,CHI S.A tunable dual-wavelength erbiumdoped fiber ring laser using a self-seeded Fabry-Pérot laser diode[J].IEEE Photonics Technology Letters,2003,15 (5):661～663.
[7] ZHANG M,WANG D N,LI H et al.Tunable dual-wavelength picosecond pulse generation by the use of two Fabry-Pérot laser diodes in an external injection seeding scheme[J].IEEE Photonics Technology Letters,2002,14(1):92～94.
[8] XU L,YAO M Y,ZHANG J F et al.A Novel technique of self-seeding of GS-DFB laser[J].Chinese Journal of Lasers,2000,27(5):427～430(in Chinese).
[9] CALVANI R,CISTERNINO F,GIRARDI R et al.All fiber self injection seeding for timing jitter reduction in a chirp compensated gainswitched DFB laser[A].ECOC98[C].Madrid:ECOC,1998.167～168.
[10] WANG Y C.Experimental study on the timing jitter of gain-switched laser diodes with photon injection[J].Acta Physics Sinica,2003,52(9):2190～2193 (in Chinese).
[11] GUNNING P,LUCEK J K,MOODIE D G et al.Gainswitched DFB laser diode pulse source using continuous wave light injection for jitter suppression and an electroabsorption modulator for pedestal suppression[J].Electron Lett,1996,32(11):1010～1011.
