Quasi-four-level co-doped Tm/Ho gadolinium vanadate laser
-
摘要: 在考虑两种离子发光的动力学进展基础上,描述了2μm双掺铥钬(Tm/Ho)系统Tm→Ho能量转移基本过程,建立双掺Tm/Ho系统准四能级速率方程,得出阈值抽运功率和斜率效率的表达式,并利用得出的结论去分析在液氮制冷下光纤耦合激光二极管(LD)端面抽运掺铥钬钒酸钆(Tm/Ho:GdVO4)激光器实验。通过实验,实现了2μmTm/Ho:GdVO4激光器的运转,在抽运功率14W时,激光输出功率3.5W,光-光转换效率25%,阈值抽运功率838mW,理论和实验有很好的一致性。同时也对实验中观测到的上转换绿荧光现象进行了定性的分析。
-
关键词:
- 固体激光 /
- 光纤耦合LD /
- Tm/Ho：GdVO4晶体 /
- 准四能级 /
- 能量转移
Abstract: Based on considering kinetic evolution of the emissions of both ions,the basic processes of energy transfer between thulium(Tm) and holmium(Ho) was analyzed,the quasi-four-level rate equation of thulium(Tm)/holmium(Ho) doped gadolinium vanadate(Tm/Ho:GdVO4) are given.The expression about threshold pump power and slope efficiency are concluded.At liquid nitrogen cooled temperature the operation of 2μm Tm/Ho:GdVO4 laser end-pumped by fiber-coupled laser diode(LD) is achieved experimentally.At 14W pump power the maximum 3.5W output power,optical-optical conversion efficiency of 25%,slope efficiency of 26.6% and pumping threshold of 838mW were obtained,theoretical results with experiment results are good agreement.The observed green fluorescence duo to result of up-conversion effect is also analyzed. -
-
[1] HENDERSON S W,SUNI P J M,HALE C P et al.Coherent laser radar at 2μm using solid-state lasers[J].IEEE Transactions on Geoscience and Remote Sensing,1993,31 (1):4～15.
[2] TACZAK T M,KILLINGER D K.Development of a tunable,narrowlinewidth,CW 2.066μm Ho:YLF laser for remote sensing of atmospheric CO2 and H2O[J].Appl Opt,1998,37(36):8460～8465.
[3] WYSS C P,LUTHY W.Performance of a Tm3+:GdVO4 microchip Iaser at 1.9μm[J].Opt Commun,1998,153:63～67.
[4] WYSS C P,LUTHY W,WEBER H P et al.Emission properties of a Tm3+:GdVO4 microchip laser at 1.9μm[J].Appl Phys,1998,B67(5):545～548.
[5] MORRIS P J,LUTHY W,WEBER H P.Laser operation and spectroscopy of Tm/Ho:GdVO4[J].Opt Commun,1994,111:493～496.
[6] ZHANG X L,WANG Y Zh,YAO B Q et al.Experiment study of 2μm wavelength Tm/Ho:YLF microchip laser[J].Laser Technology,2002,26(6):407～408(in Chinese).
[7] FAL CONIERI M,LANZI A,SALVETTI G.Spectroscopic investigation of the visible and mid-infrared emission in Tm-and Ho-doped YAG and YLF crystals[A].Proc of CLEO[C].Europe:CLEO,1994.132～133.
[8] BARNES N P,FILER E D,MORRISON C A.Ho:Tm lasers:Ⅰ Theoretical[J].IEEE J Q E,1996,32(1):92～103.
[9] TACZAK T M.Development of a tunable,narrow linewidth 2.066 micrometer holmium,thulium:yttrium lithium fluoride laser for openpath remote sensing of atmospheric carbon dioxide and water vapor[D].South Florida:University of South Florida,1996.46～48.
[10] DOSHIDA M,TERAGUCHI K,OBARA M.Gain measurement and upconversion analysis in Tm3+,Ho3+ co-doped alumino-zireo-fluoride glass[J].IEEE J Q E,1995,31 (5):910～915.
[11] CHEN Y F,LAN Y P,WANG S C.Influence of energy-transfer upconversion on the performance of high-power diode-end-pumped CW lasers[J].IEEE J Q E,2000,36(5):615～619.
