Blumlein快放电电路传输线电容和储能电容的研制

基金项目:

国家自然科学基金资助项目(60278009)

详细信息

Development of transmission line capacitor and stored capacitor in Blumlein fast discharge circuit

1.
Department of Electric Engineering, Harbin Institute of Technology, Harbin 150001, China;
2.
National Key Laboratory of Tunable Laser Technology, Harbin Institute of Technology, Harbin 150001, China

摘要: 为减小Blum lein电路中的寄生电阻与电感,自行设计了传输线电容与储能电容,以平行平板电容器结构代替了原来的无感电容与传输线电容的结构,使得电路中寄生电感下降1倍以上,电路性能得到很大改进,满足了S2激光器产生辉光放电的要求.
- 传输线电容 /
- 储能电容 /
- 无感设计 /
- 快放电电路
Abstract: In order to reduce the parasitic inductance and resistance of Blumlein circuit,the transmission line capacitor and stored capacitor are designed and manufactured by ourselves,which are substituted by the plate capacitors instead of the old non-inductance capacitor and transmission line.The parasitic inductance of Blumlein circuit decreases once,the pulsed fast discharge power supply works steadily,it is important for diatomic sulfur laser.
- transmission line capacitor /
- stored capacitor /
- non-inductance design /
- fast discharge circuit

[1]	吴辉,吴建强.硫双原子分子激光器脉冲快放电电源的研究[J].光电子·激光,2003,14(3):235～238.
[2]	高允贵.N2分子激光器Blumlein电路开路输出电压的研究[J].中国激光,1982,10(3):147～151.
[3]	吴恒莱.硫双原子分子横向脉冲快放电激光增益的研究[D].哈尔滨:哈尔滨工业大学,1997.29～40.
[4]	蒋正龙,姚宗干,林福昌.提高脉冲电容器储能密度的试验研究[J].电工技术杂志,1996(4):2～3.
