色分离光栅对光束近场调制影响实验研究

详细信息

Experiment research of the effect of the color seperating grating on the near field modulation of the beam

1.
Research Center of Laser Fusion, CAEP, Mianyang 621900, China;
2.
Department of Physics, Sichuan University, Chengdu 610064, China;
3.
National Synchrotron Radiation Laboratory, University of Science and Technology of China, Hefei 230029, China

摘要: 介绍了一种用于惯性约束聚变研究的CSG衍射光栅研制情况,衍射光栅的制作采用离子束刻蚀的方法,光栅刻蚀面积为80mm×80mm。利用星光Ⅱ高功率固体激光装置实验平台对光路中插入衍射光栅后的光束近场调制变化进行了实验测试。实验结果表明,在低功率密度条件下(0.005GW/cm2)光路中插入CSG衍射光栅后,光束近场调制度没有明显的增加,相对于光束本身的调制来说,由光栅带来的调制为细微的小量调制。
- 衍射光栅 /
- 高功率固体激光驱动器 /
- 色分离光栅 /
- 光束近场调制度 /
- 功率密度
Abstract: The development of the color seperating gratings(CSGs),used in the field of ICF,is introduced.The CSG's area is 80mm×80mm.The change of beam near field percentage modulation is tested when the CSG is put in the optics system on the XGⅡ laser facility.Experimental results show that no increase of beam near field percentage modulation is found when the CSG is put in the system under the low power density of 0.005GW/cm2.
- diffraction gratings /
- high power solid-state laser facility /
- color separation gratings /
- near field percentage modulation of the beam /
- power density

[1]	BETT T H,SMITH I C.Diffractive beam samplers for large aperture beam diagnostics[J].SPIE,1999,3492:445～452.
[2]	BRITTER J A.Low efficiency gratings for 3rd harmonic diagnosticsapplication[J].SPIE,1997,2633:121～128.
[3]	BRITTEN J A,HERMAN S M,SUMMERS L J et al.Manufacture optical performance and laser damage characteristics of diffractive optics for the national ignition facility[J].SPIE,1998,3578:337～340.
[4]	DIXIT S N,RUSHFORD M C,THOMAS I M et al.Color separation gratings for diverting the un-converted light away from the NIF targets[J].SPIE,1996,3047:463～470.
[5]	BARTON I M,BLAIR P,WADDIE A J et al.Beam-shaping diffractive optical elements for high-power solid-state laser systems[J] SPIE,1998,3492:437～444.
[6]	TOUZET B,FLAMAND J,THEVENON A et al.Focusing transmission gratings for high energy lasers[J].SPIE,1998,3492:426～436.
[7]	柴立群,杨李茗,许乔.用于ICF驱动器的取样光栅的矢量分析与计算[J].强激光与粒子束,2002,14(2):270～274.
[8]	王成程,马驰,郑万国 et al.70mm×70mm取样光栅性能测试研究[J].光学与光电技术,2004,2(5):27～30.
[9]	袁静,魏晓峰,郭永康 et al.用于ICF驱动器的色分离相位光栅的研究[J].激光技术,1999,23(3):168～172.
