强激光束辐照下窗口材料热力效应数值模拟

基金项目:

国家八六三计划资助项目(863-802-4)

详细信息

Thermal deformation of optical windows irradiated by high power laser beam

1.
Institute of Fluid Physics, CAEP, Mianyang 621900, China;
2.
Institute of Laser Physics and Chemistry, Sichuan University, Chengdu 610064, China

摘要: 基于三维瞬态热传导方程和弹性应力-应变方程,研究了空心环形强激光束(波长1.315μm)辐照下白宝石窗口温度、变形和应力的分布规律;研究了空心矩形强激光束(波长3.8μm)辐照下氟玻璃窗口温度、变形和应力的分布规律。采用三维有限元模型,数值模拟了强激光在窗口材料中产生的热和力学效应,为强激光窗口元件的选择以及热效应对光束质量影响的评估提供了参考。计算中,激光能量吸收采用体吸收,并考虑了光强分布的空间梯度以及光强在窗口内的衰减。
- 激光光学 /
- 强激光 /
- 光学窗口 /
- 温度场 /
- 变形 /
- 应力
Abstract: Based on three dimensional transient heat conduction equation and elastic stress-strain equation,the temperature rise,distortion and equivalent stress distribution of white bijou window irradiated by high power annular beam(λ=(1.315)μm) are simulated using a three dimensional finite element model(FEM).The temperature rise,distortion and equivalent stress distribution of fluoride glass window induced by high power hollow rectangular laser beam(λ=3.8μm) are also simulated.Laser intensity spatial gradient and attenuation in window are considered in computational model.
- laser optics /
- high power laser /
- optical window /
- temperature field /
- distortion /
- stress

[1]	MANSELL J D,HENNAW I J,GUSTAFSON E K et al.Evaluating the effect of transmissive optic thermal lensing on laser beam quality with a Shack-Hartmann[J].Appl Opt,2001,40(3):366～374.
[1]	CLANDE A K.Materials for high-power laser optics:figures of merit for thermally induced beam distortions[J].Opt Engng,1997,36(6): 1586～1595.
[2]	陈金宝,刘泽金,蒋志平et al.非稳腔DF激光窗口热效应及其对远场光斑的影响[J].强激光与粒子束,1994,6(2):243～249.
[3]	马毅勇,程祖海,张耀宇.高功率激光与窗口热变形分析的有限元方法[J].强激光与粒子束,1999,11(1):6～10.
[4]	陈发良,李有宽.环形分布激光束引起光学窗口镜热变形理论分析[J].强激光与粒子束,2003,15(8):736～740.
[5]	HARR IS D C.Materials for infrared windows and domes(properties and performances)[M].Bellingham:SPIE Optical Enginerrring Press,1999.126～129.
[6]	李景镇.光学手册[M].西安:陕西科学技术出版社,1985.1328～1337.
[7]	竹内洋一.热应力[M].北京:科学出版社,1977.47～50.
