Expermi ental study of reflectivity measurement of single wavelength by cavity ring-down method
-
摘要: 分析了反射率光腔衰荡法测量原理的近似条件,讨论了共焦腔的失调特性,计算了腔镜反射率对衰荡信号的影响。在此基础上,为减少OPO激光束的衍射损耗引入的测量误差,选择He-Ne激光作导引光,建立以共焦腔为衰荡腔的单波长反射率测量装置。利用直腔和折叠腔对腔镜和插入镜片的反射率进行了实验测量。直腔方式下测量的均方差小于6×10-6。分析表明,光腔衰荡法只适用于高反镜反射率的测量;在光路调节中采用具有对数变换功能的示波器,可以提高测量精度。Abstract: Approximate condition of reflectivity measurement with cavity ring-down method is analyzed,misadjustment characteristic of confocal cavity is discussed and influence of cavity mirror's reflectivity on ring-down signal is calculated.In order to lessen metrical precision from diffraction losses of OPO laser,based on the above analyses,a reflectivity measuring system for single wavelength is set up with cavity ring-down method,whose ring-down cavity is confocal cavity.Experimental measurement of reflectivity of cavity mirror and inserted mirror is carried out.The measurement RMS in linear cavity is less than 6×10-6.Results show that cavity ring-down method is only for higher reflectivity,and metrical precision can be improved by using logarithm transform of oscillograph in adjustment of the optical cavity.
-
Keywords:
- optical measurement /
- reflectivity /
- cavity ring-down /
- metrical precision /
- misadjustment /
- confocal cavity
-
-
[1] 孙福革,孙龙,戴东旭.用光腔衰荡光谱方法精确测量高反镜的反射率 [J].中国激光,1999,A26(1):35～38. [1] 盛新志,房本杰,孙福革.复合衰荡光腔技术精确检测COIL腔镜高反射率 [J].强激光与粒子束,1998,10(2):199～202. [2] 赵宏太,柳晓军,詹明生.腔衰荡法四腔镜反射率及腔内吸收测量 [J].量子电子学报,2001,18(3):213～216. [3] 赵宏太,柳晓军,王谨 et al.用光腔衰荡测定腔镜及镜片的反射率 [J].光电子 · 激光,2001,12(1):71～73. [4] ANDERSON D Z,FRISCH J C,MASSER C S.Mirror reflector based on optical cavity decay time [J].Appl Opt,1984,23(8):1238～1242.
[5] SANDERSON R L,STEIFER W.Laser resonator with tilted reflectors [J].Appl Opt,1969,8(11):2241～2248.
[6] 易亨瑜,吕百达,胡晓阳.腔长失调对光腔衰荡光谱法测量精度的影响 [J].强激光与粒子束,2004,16(8):547～551. [7] 易亨瑜,胡晓阳,彭勇 et al.探测器孔径大小对衰荡腔测量精度的影响 [J].激光技术,2004,28(3):231～236.
