Temperature measurement sensitivity of a practical real-time temperature measurement system
-
摘要: 基于基尔霍夫定律,利用半导体激光器InGaAs/I及钽酸锂热释电探测器设计了一种实用化的实时测温系统。基于该系统A/D转换器件的分辨率、V(T)-T曲线的温度灵敏度及其与测温范围间的制约关系,确定了系统应选用16位的芯片为其A/D转换器件;基于该系统的测温精度、V(T)-T曲线的相对温度灵敏度及其与波长间的关系,对其工作波长的优化选择进行了进一步的讨论;基于探头的温度分辨力、A/D转换器件的分辨率以及与V(T)-T曲线的温度灵敏度间的制约关系,对其波长带宽的优化设计进行了进一步的分析,并给出了系统在673K～1473K内的测温灵敏度。对系统进行优化设计后,在测温范围的低温段,其灵敏度不低于0.5K;在测温范围的高温段,则不低于0.1K。在673K～1473K内,其测温不确定度不低于0.3%。Abstract: Based on the Kirchhoff law,a practical temperature real-time measurement system using laser diode InGaAs/I and LiTaO3 pyroelectric detector is presented.By means of analyzing the relationships among resolving power of A/D converter,temperature measurement sensitivity of V(T)-T curve and temperature measurement range,16bite A/D converter for this instrument is determined.According to the relationships among temperature measurement accuracy,relative temperature measurement sensitivity of V(T)-T curve and waveleng ths,further optimal wavelength is discussed.Based on the relationships among resolving power of the detector and A/D converter and temperature sensitivity of V(T)-T curve,further optimal wavelength bandwidth is analyzed.Temperature measurement sensitivity of the instrument at 673K～1473K is given.Temperature measurement sensitivity is above 0.5K at lower temperatures and above 0.1K at higher temperatures at 673K～1473K after using optimal parameters.Temperature measurement inaccuracy at 673K～1473K exceeds 0.3%.
-
-
[1] KHAN M A,ALLEMAND C,EAGAR T W.Noncontact temperature measurement Ⅰ:interpolation based techniques[J].Rev Sci Instrum,1991,62(2):392～402.
[2] HAHN J W,RHEE C.Reference wavelength method for a two-color pyrometer[J].Appl Opt,1987,26(24):5276～5279.
[3] HUNTER G B,ALLEHAND C D,EAGER T W.Multiwavelength pyrometer[J].Opt Engng,1985,24(6):1081～1085.
[4] DEWITT D P.Inferring temperature from optical radiation measurements[J].Opt Engng,1986,25(4):596～601.
[5] KRIVTZUM V,GRASS B,HERGENRODER R et al.Temperature measurement of liquids by differential absorption of two diode laser[J].Applied Spectroscopy,2001,55(9):1251～1258.
[6] FAN C H,LONGTIN J P.Laser-based measurement of temperature or concentration change at liquid surface[J].Journal of Heat Transfer,Transactions ASME,2000,122(4):757～762.
[7] KEE H H,LEES G P,NEWSON T P.Technique for measuring distributed temperature with 35cm spatial resolution utilizing the Landau-Placzek ratio[J].IEEE Photon Technol Lett,2000,12(7):873～875.
[8] 胡瑞华,栾松,孙宁克.可同时测量温度及发射率的辐射温度计[J].红外技术,1998,20(2):21～22. [9] 施德恒,黄国庆,刘玉芳.一种实用化实时测温系统的工作波长的优化设计[J].中国激光,2003,30(6):545～550. [10] 施德恒,黄国庆,刘玉芳 et al.一种实用化实时测温系统的优化设计[J].光学学报,2003;23(11):1394～1401. [11] 施德恒,黄国庆,刘玉芳.光源对测温系统测温精度及测温范围的影响[J].光电子*激光,2003,14(5):529～533. [12] TAMURA Y,TATSUWAKI M,SUGIMURA T et al.Temperature measure of steel in the furnace[A].Temperature,its Measurement and Control in Science and Industry[C].New York:American Institute of Physics,1982.505～512.
[13] 王勇,廖延标,辛军 et al.实用化双折射式光纤温度传感器系统最佳设计[J].光学学报,1999,19(1):87～92. [14] COATES P B.Analytic estimation of systematic errors in photoelectric pyrometry[J].High Temperatures-High Pressures,1985,17:507～518.
