薄膜偏光分束镜的设计与性能测试

详细信息

The design and test of thin film polarizing beam splitting prism

摘要: 基于MacNeille薄膜偏光分束镜的设计原理,以LaK2(1.64)玻璃为基底,采用ZrO2和SiO2为高低膜料进行膜系设计。对制作的棱镜进行测试,结果表明,透射p光偏振特性优良,其消光比高达2.1×10-4,同时发现其消光比受视场角的影响比较大,入射角越小其消光比越高。
- 薄膜偏光分束镜 /
- 消光比 /
- 视场角 /
- 光学性能测试
Abstract: The thin film polarizing beam splitting prism is designed based on MacNeille type by using LaK2 substrate and ZrO2,SiO2 thin film material.The test show that the prism has excellent polarizing character,the splitting character is good at the range of 550nm～750nm,the extinction ratio is 2.1×10-4,the extinction ratio turns big when the incident angle change small.
- thin film polarizing beam splitting prism /
- extinction ratio /
- incident angle /
- the test of optic character

[1]	李景镇,苏世学,赵俊民 et al.光学手册 [M].西安:陕西科学技术出版社,1985.500～502.
[2]	金国藩,李景镇.激光测量学 [M].北京:科学出版社,1998.221～224.
[3]	MAcNEILE S M.Beam splitter [P].U S Patent:2403731,1946-06-06.
[4]	BUCHMAN W W.Singles wavelength thin-film polarizers [J].J O S A,1997,61:1604～1606.
[5]	胡海洋,范正修.大尺寸宽带偏振薄膜的制备与测试 [J].中国激光,2000,A27(2):117～122.
[6]	顾培夫.一种棱镜分光膜的设计和制备 [J].光学技术,1981(4):17～20.
[7]	何孟权,郑颖君.激光偏振分光镜的设计和测试 [J].光学技术,1983(6):21～26.
[8]	强西林,高明.棱镜偏振分光膜研究 [J].西安工业学院报,2000,20(2):106～109.
[9]	吴自勤,王兵.薄膜生长 [M].北京:科学出版社,2001.188～213.
[10]	田民波,刘德令.薄膜科学与技术手册 [M].北京:机械工业出版社,1991.263～380.
[11]	LI H F,HUANG H C.Broadband,large acceptance angle polarizing beam splitter for reflective LCD projectors [J].Proc SPIE,2000,3954:186～196.
[12]	王召兵,李国华,陆书龙 et al.高消光比自动测试系统的研究 [J].中国激光,2000,A27(5):415～417.
