Microstructure and corrosion performance of laserclad 316L stainless steel coating
-
摘要: 使用激光多道搭接法在45#钢基底表面熔覆316L不锈钢粉末涂层,对比研究了激光涂层和对应商用棒材的微观结构及其分别在2mol NaCl,1mol FeCl3和0.5mol HCl溶液中的阳极极化腐蚀行为。结果表明,单层激光熔覆粉末涂层受基底钢材稀释的影响,涂层最终的微观结构由马氏体和极少量的奥氏体组成。激光熔覆粉末涂层和商用棒材在上述溶液中表现出相似的极化行为,阳极极化和阴极极化的超电位都遵循Tafel关系,表现出很好的钝化性能和点蚀抗力。与商用棒材相比,涂层材料的自腐蚀电流大、自腐蚀电位低、极化电阻小、抗腐蚀能力略有下降。Abstract: 316L stainless steel powders were clad onto AISI 1045 steel substrate using laser multi-track overlapping process.The microstructure and anodic polarization corrosion behavior in 2mol NaCl,1mol FeCl3 and 0.5mol HCl aqueous solutions of the clad layer and its commercial counterpart bulk 316L stainless steel were comparatively investigated.The chemical composition of the clad layer resulted from dilution from the substrate is quite different from that of the original 316L stainless steel powders,the final microstructure of the clad layer comprised predominant martensite and very small amount of residual austenite.The anodic polarization behavior of the clad layer was similar to that of its commercial counterpart bulk in the aqueous solutions mentioned above.There exists Tafel relationship between the superpotential of anodic and cathodic polarization and current for both the clad layer and the bulk.The clad layer displays good passive performance and pitting corrosion resistance.Compared with the bulk,however,the clad layer has larger self-corrosive current density,lower potential and smaller polarization resistance,and its corrosion resistance slightly degrades.
-
Keywords:
- laser cladding /
- 316L stainless steel /
- microstructure /
- anodic polarization
-
-
[1] ATAMERT S,BHADESHIA H K D H.Comparison of the microstructure and abrasive wear properties of stelllite hardfacing alloys deposited by arc welding and laser cladding[J].Met all Trans A,1989,20A:1037～1054.
[1] LI Q,ZHANG D W,LEI T C et al.Comparison of laser clad and furnace melt Ni-based alloy microstructures[J].Surf Coat Tech-nol,2001,137(2～3):122～135.
[2] LI Q,SONG G M,ZHANG Y Z et al.Microstructure and dry sliding wear behavior of laser clad Ni-based alloy coating with the addition of SiC[J].Wear,2003,254(3～4):222～229.
[3] MONSON P J E,STEEN W M.Comparison of laser hardfacing with conventional processes[J].Surf Engng,1990,6(3):185～193.
[4] YANG S,ZHONG M,LIU W.TiC particulate composite coating produced in situ by laser cladding[J].Mater Sci Engng,2003,A343:57～62.
[5] RENAND L,FOUQUET F,MILLET J P et al.Microstructural characterization and comparative electrochemical behavior of Fe-Ni-Cr and Fe-Ni-Cr-P laser surface alloys[J].Mater Sci Engng,1991,A134:1049～1053.
[6] WEERASINGHE V M,STEEN W M,WEST D R F.Laser deposited austenitic stainless steel clad layers[J].Surf Engng,1987,3(2):147～153.
[7] LI R,FERREIRA M G S,ANJOS M et al.Localized corrosion performance of laser surface cladded UNS S44700 superferritic stainless steel on mild steel[J].Surf Coat Technol,1996,88:96～102.
[8] LI R,FERREIRA M G S,ANJOS M et al.Localized corrosion of laser surface cladded UNS S31254 superaustenitic stainless steel on mild steel[J].Surf Coat Technol,1996,88:90～95.
[9] ANJOS M A,VILAR R,QIU Y Y.Laser cladding of ASTMS31254 stainless steel on a plain carbon steel substrate[J].Surf Coat Technol,1997,92:142～149.
[10] 毛协民,傅恒志,FRENK A et al.Co-Cr-C合金激光重熔时γ-Co与Cr7-xCoxC3的共晶共生生长研究[J].材料科学进展,1992,6(4):295～300. [11] BRUCK G J.High-power laser beam cladding[J].J Met,1987,2:10～13.
[12] 崔昆.钢铁材料及有色金属材料[M].北京:机械工业出版社,1981.223～225. [13] SEDRICKS A J.Corrosion of Stainless Steel[M].New York:John Wiley and Sons,1979.77～93.
